SEIKO
小型、低功耗、高功能‐電子零件
實現小型化、低能耗、高性能
誕生於石英表研發的電子零件被廣泛應用於智能手機、數碼家電、
汽車和產業用設備等各種領域。
半導體與石英晶振具有小型、低電壓驅動、耗電低、高精度的特點，
能夠為設備的小型化、高性能、驅動時間的延長等做出貢獻。
其中，CMOS IC由於可以在嚴酷的環境下穩定運行，多被用於汽車產品上，其實力獲得了高度評價。
此外，我們的石英振盪器用IC的市場份額高居全球榜首。
在鐘錶零件的開發製造過程中積累的電池技術及磁鐵、
高功能金屬產品群如今也為電子設備的小型化、高功能化做著貢獻。


SUPER-SMALL PACKAGE HIGH-PRECISION VOLTAGE DETECTOR
The S-808xxC series is a series of high-precision voltage detectors developed using
CMOS process. The detection voltage is fixed internally with an accuracy of
2.0%.  Two output forms, Nch open-drain and CMOS output, are available.
Super-low current consumption and miniature package lineup
can meet demand from the portable device applications.

Features
Super-low current consumption
High-precision detection voltage
Operating voltage range
Hysteresis characteristics
Detection voltage
Output form
Lead-free products

Applications
Battery checkers
Power failure detectors
Power monitor for portable equipments such as pagers, calculators,
electronic notebooks and remote controllers.
Constant voltage power monitor for cameras, video equipments and communication devices.
Power monitor for microcomputers and reset for CPUs.

超小型高精度電壓檢測器
S-808xxC系列是採用CMOS工藝開發的一系列高精度電壓檢測器。
檢測電壓在內部固定，精度為2.0％。
提供兩種輸出形式，Nch開漏和CMOS輸出。
超低電流消耗和微型封裝陣容可滿足便攜式設備應用的需求。

特徵
超低電流消耗
高精度檢測電壓
工作電壓範圍
滯後特性
檢測電壓
輸出表格
無鉛產品

應用
電池檢查器
停電檢測器
便攜式設備的功率監視器，如尋呼機，計算器，電子筆記本和遙控器。
用於攝像機，視頻設備和通信設備的恆壓電源監控器。
用於微型計算機的電源監視器和用於CPU的複位。


型號	機能	檢測電壓	精度	工作電壓	消耗電流	輸出方式	封裝
					(典型值)
S-1009 series	270nA超低消費消耗電流	0.8~4.6 V	±0.5%	0.6~10 V	270nA	Nch	SC-82AB
						opendrain	SOT-23-5
						CMOS
S-1000 series	350nA超低消費消耗電流	1.5~4.6 V	±1%	0.95~5.5 V	350nA	Nch	SNT-4A
					(Vdd=1.5V)	opendrain	SC-82AB
						CMOS	SOT-23-5
S-808xxC series	標準產品	0.8~6.0 V	±2%	0.65~5.0V	0.8uA	Nch	TO-92
				(Det, 1.4V or less)	(Vdd=3.5V)	opendrain	SNT-4A
				0.95~10V		CMOS	SC-82AB
				(Det. 1.5V or more)			SOT-23-5
							SOT-89-3
S-801 series	內置延遲電路	2.2~6.0 V	±2%	0.95~10 V	1.3uA	Nch	SNT-4A
	(內部設定延遲時間)				(Vdd=3.5V)	opendrain	SOT-23-5
						CMOS
S-809xxC series	內置延遲電路	1.3~6.0 V	±2%	0.7~10 V	1.1uA	Nch	SNT-4A
	(外部設定延遲時間)				(Vin=3.5V)	opendrain	SC-82AB
						CMOS	SOT-23-5



SC-82AB	SOT-23-5	SOT-89-3
S-80808CNNB-B9MT2G
S-80809CNNB-B9NT2G
S-80810CNNB-B9OT2G
S-80811CNNB-B9PT2G
S-80812CNNB-B9QT2G
S-80813CNNB-B9RT2G
S-80814CNNB-B9ST2G
S-80815CNNB-B8AT2G	S-80815CNMC-B8AT2G	S-80815CNUA-B8AT2G
S-80816CNNB-B8BT2G	S-80816CNMC-B8BT2G	S-80816CNUA-B8BT2G
S-80817CNNB-B8CT2G	S-80817CNMC-B8CT2G	S-80817CNUA-B8CT2G
S-80818CNNB-B8DT2G	S-80818CNMC-B8DT2G	S-80818CNUA-B8DT2G
S-80819CNNB-B8ET2G	S-80819CNMC-B8ET2G	S-80819CNUA-B8ET2G
S-80820CNNB-B8FT2G	S-80820CNMC-B8FT2G	S-80820CNUA-B8FT2G
S-80821CNNB-B8GT2G	S-80821CNMC-B8GT2G	S-80821CNUA-B8GT2G
S-80822CNNB-B8HT2G	S-80822CNMC-B8HT2G	S-80822CNUA-B8HT2G
S-80823CNNB-B8IT2G	S-80823CNMC-B8IT2G	S-80823CNUA-B8IT2G
S-80824CNNB-B8JT2G	S-80824CNMC-B8JT2G	S-80824CNUA-B8JT2G
		S-80824KNUA-D2BT2G*2
S-80825CNNB-B8KT2G	S-80825CNMC-B8KT2G	S-80825CNUA-B8KT2G
S-80826CNNB-B8LT2G	S-80826CNMC-B8LT2G	S-80826CNUA-B8LT2G
S-80827CNNB-B8MT2G	S-80827CNMC-B8MT2G	S-80827CNUA-B8MT2G
S-80828CNNB-B8NT2G	S-80828CNMC-B8NT2G	S-80828CNUA-B8NT2G
S-80829CNNB-B8OT2G	S-80829CNMC-B8OT2G	S-80829CNUA-B8OT2G
S-80830CNNB-B8PT2G	S-80830CNMC-B8PT2G	S-80830CNUA-B8PT2G
S-80831CNNB-B8QT2G	S-80831CNMC-B8QT2G	S-80831CNUA-B8QT2G
S-80832CNNB-B8RT2G	S-80832CNMC-B8RT2G	S-80832CNUA-B8RT2G
S-80833CNNB-B8ST2G	S-80833CNMC-B8ST2G	S-80833CNUA-B8ST2G
S-80834CNNB-B8TT2G	S-80834CNMC-B8TT2G	S-80834CNUA-B8TT2G
S-80835CNNB-B8UT2G	S-80835CNMC-B8UT2G	S-80835CNUA-B8UT2G
S-80836CNNB-B8VT2G	S-80836CNMC-B8VT2G	S-80836CNUA-B8VT2G
S-80837CNNB-B8WT2G	S-80837CNMC-B8WT2G	S-80837CNUA-B8WT2G
S-80838CNNB-B8XT2G	S-80838CNMC-B8XT2G	S-80838CNUA-B8XT2G
S-80839CNNB-B8YT2G	S-80839CNMC-B8YT2G	S-80839CNUA-B8YT2G



SNT-4A	TO-92*1
S-80808CNPF-B9MTFG
S-80809CNPF-B9NTFG
S-80810CNPF-B9OTFG
S-80811CNPF-B9PTFG
S-80812CNPF-B9QTFG
S-80813CNPF-B9RTFG
S-80814CNPF-B9STFG
S-80815CNPF-B8ATFG	S-80815CNY-x-G
S-80816CNPF-B8BTFG	S-80816CNY-x-G
S-80817CNPF-B8CTFG	S-80817CNY-x-G
S-80818CNPF-B8DTFG	S-80818CNY-x-G
S-80819CNPF-B8ETFG	S-80819CNY-x-G
S-80820CNPF-B8FTFG	S-80820CNY-x-G
S-80821CNPF-B8GTFG	S-80821CNY-x-G
S-80822CNPF-B8HTFG	S-80822CNY-x-G
S-80823CNPF-B8ITFG	S-80823CNY-x-G
S-80824CNPF-B8JTFG	S-80824CNY-x-G
	S-80824KNY-x-G *3
S-80825CNPF-B8KTFG	S-80825CNY-x-G
S-80826CNPF-B8LTFG	S-80826CNY-x-G
S-80827CNPF-B8MTFG	S-80827CNY-x-G
S-80828CNPF-B8NTFG	S-80828CNY-x-G
S-80829CNPF-B8OTFG	S-80829CNY-x-G
S-80830CNPF-B8PTFG	S-80830CNY-x-G
S-80831CNPF-B8QTFG	S-80831CNY-x-G
S-80832CNPF-B8RTFG	S-80832CNY-x-G
S-80833CNPF-B8STFG	S-80833CNY-x-G
S-80834CNPF-B8TTFG	S-80834CNY-x-G
S-80835CNPF-B8UTFG	S-80835CNY-x-G
S-80836CNPF-B8VTFG	S-80836CNY-x-G
S-80837CNPF-B8WTFG	S-80837CNY-x-G
S-80838CNPF-B8XTFG	S-80838CNY-x-G
S-80839CNPF-B8YTFG	S-80839CNY-x-G
S-80840CNPF-B8ZTFG	S-80840CNY-x-G
S-80841CNPF-B82TFG	S-80841CNY-x-G
S-80842CNPF-B83TFG	S-80842CNY-x-G
S-80843CNPF-B84TFG	S-80843CNY-x-G
S-80844CNPF-B85TFG	S-80844CNY-x-G
S-80845CNPF-B86TFG	S-80845CNY-x-G
S-80846CNPF-B87TFG	S-80846CNY-x-G
	S-80846KNY-x-G *4
S-80847CNPF-B88TFG	S-80847CNY-x-G
S-80848CNPF-B89TFG	S-80848CNY-x-G
S-80849CNPF-B9ATFG	S-80849CNY-x-G
S-80850CNPF-B9BTFG	S-80850CNY-x-G
S-80851CNPF-B9CTFG	S-80851CNY-x-G



SNT-4A	TO-92*1
S-80852CNPF-B9DTFG	S-80852CNY-x-G
S-80853CNPF-B9ETFG	S-80853CNY-x-G
S-80854CNPF-B9FTFG	S-80854CNY-x-G
S-80855CNPF-B9GTFG	S-80855CNY-x-G
S-80856CNPF-B9HTFG	S-80856CNY-x-G
S-80857CNPF-B9ITFG	S-80857CNY-x-G
S-80858CNPF-B9JTFG	S-80858CNY-x-G
S-80859CNPF-B9KTFG	S-80859CNY-x-G
S-80860CNPF-B9LTFG	S-80860CNY-x-G



SC-82AB	SOT-23-5	SOT-89-3
S-80840CNNB-B8ZT2G	S-80840CNMC-B8ZT2G	S-80840CNUA-B8ZT2G
S-80841CNNB-B82T2G	S-80841CNMC-B82T2G	S-80841CNUA-B82T2G
S-80842CNNB-B83T2G	S-80842CNMC-B83T2G	S-80842CNUA-B83T2G
S-80843CNNB-B84T2G	S-80843CNMC-B84T2G	S-80843CNUA-B84T2G
S-80844CNNB-B85T2G	S-80844CNMC-B85T2G	S-80844CNUA-B85T2G
S-80845CNNB-B86T2G	S-80845CNMC-B86T2G	S-80845CNUA-B86T2G
S-80846CNNB-B87T2G	S-80846CNMC-B87T2G	S-80846CNUA-B87T2G
		S-80846KNUA-D2CT2G*3
S-80847CNNB-B88T2G	S-80847CNMC-B88T2G	S-80847CNUA-B88T2G
S-80848CNNB-B89T2G	S-80848CNMC-B89T2G	S-80848CNUA-B89T2G
S-80849CNNB-B9AT2G	S-80849CNMC-B9AT2G	S-80849CNUA-B9AT2G
S-80850CNNB-B9BT2G	S-80850CNMC-B9BT2G	S-80850CNUA-B9BT2G
S-80851CNNB-B9CT2G	S-80851CNMC-B9CT2G	S-80851CNUA-B9CT2G
S-80852CNNB-B9DT2G	S-80852CNMC-B9DT2G	S-80852CNUA-B9DT2G
S-80853CNNB-B9ET2G	S-80853CNMC-B9ET2G	S-80853CNUA-B9ET2G
S-80854CNNB-B9FT2G	S-80854CNMC-B9FT2G	S-80854CNUA-B9FT2G
S-80855CNNB-B9GT2G	S-80855CNMC-B9GT2G	S-80855CNUA-B9GT2G
S-80856CNNB-B9HT2G	S-80856CNMC-B9HT2G	S-80856CNUA-B9HT2G
S-80857CNNB-B9IT2G	S-80857CNMC-B9IT2G	S-80857CNUA-B9IT2G
S-80858CNNB-B9JT2G	S-80858CNMC-B9JT2G	S-80858CNUA-B9JT2G
S-80859CNNB-B9KT2G	S-80859CNMC-B9KT2G	S-80859CNUA-B9KT2G
S-80860CNNB-B9LT2G	S-80860CNMC-B9LT2G	S-80860CNUA-B9LT2G



SC-82AB	SOT-23-5	SOT-89-3
S-80808CLNB-B7MT2G
S-80809CLNB-B7NT2G
S-80810CLNB-B7OT2G
S-80811CLNB-B7PT2G
S-80812CLNB-B7QT2G
S-80813CLNB-B7RT2G
S-80814CLNB-B7ST2G
S-80815CLNB-B6AT2G	S-80815CLMC-B6AT2G	S-80815CLUA-B6AT2G
S-80816CLNB-B6BT2G	S-80816CLMC-B6BT2G	S-80816CLUA-B6BT2G
S-80817CLNB-B6CT2G	S-80817CLMC-B6CT2G	S-80817CLUA-B6CT2G
S-80818CLNB-B6DT2G	S-80818CLMC-B6DT2G	S-80818CLUA-B6DT2G
S-80819CLNB-B6ET2G	S-80819CLMC-B6ET2G	S-80819CLUA-B6ET2G
S-80820CLNB-B6FT2G	S-80820CLMC-B6FT2G	S-80820CLUA-B6FT2G
S-80821CLNB-B6GT2G	S-80821CLMC-B6GT2G	S-80821CLUA-B6GT2G
S-80822CLNB-B6HT2G	S-80822CLMC-B6HT2G	S-80822CLUA-B6HT2G
S-80823CLNB-B6IT2G	S-80823CLMC-B6IT2G	S-80823CLUA-B6IT2G
S-80824CLNB-B6JT2G	S-80824CLMC-B6JT2G	S-80824CLUA-B6JT2G
S-80825CLNB-B6KT2G	S-80825CLMC-B6KT2G	S-80825CLUA-B6KT2G
S-80826CLNB-B6LT2G	S-80826CLMC-B6LT2G	S-80826CLUA-B6LT2G
S-80827CLNB-B6MT2G	S-80827CLMC-B6MT2G	S-80827CLUA-B6MT2G
S-80828CLNB-B6NT2G	S-80828CLMC-B6NT2G	S-80828CLUA-B6NT2G
S-80829CLNB-B6OT2G	S-80829CLMC-B6OT2G	S-80829CLUA-B6OT2G
S-80830CLNB-B6PT2G	S-80830CLMC-B6PT2G	S-80830CLUA-B6PT2G
S-80831CLNB-B6QT2G	S-80831CLMC-B6QT2G	S-80831CLUA-B6QT2G
S-80832CLNB-B6RT2G	S-80832CLMC-B6RT2G	S-80832CLUA-B6RT2G
S-80833CLNB-B6ST2G	S-80833CLMC-B6ST2G	S-80833CLUA-B6ST2G
S-80834CLNB-B6TT2G	S-80834CLMC-B6TT2G	S-80834CLUA-B6TT2G
S-80835CLNB-B6UT2G	S-80835CLMC-B6UT2G	S-80835CLUA-B6UT2G
S-80836CLNB-B6VT2G	S-80836CLMC-B6VT2G	S-80836CLUA-B6VT2G
S-80837CLNB-B6WT2G	S-80837CLMC-B6WT2G	S-80837CLUA-B6WT2G
S-80838CLNB-B6XT2G	S-80838CLMC-B6XT2G	S-80838CLUA-B6XT2G
S-80839CLNB-B6YT2G	S-80839CLMC-B6YT2G	S-80839CLUA-B6YT2G
S-80840CLNB-B6ZT2G	S-80840CLMC-B6ZT2G	S-80840CLUA-B6ZT2G
S-80841CLNB-B62T2G	S-80841CLMC-B62T2G	S-80841CLUA-B62T2G
S-80842CLNB-B63T2G	S-80842CLMC-B63T2G	S-80842CLUA-B63T2G
S-80843CLNB-B64T2G	S-80843CLMC-B64T2G	S-80843CLUA-B64T2G
S-80844CLNB-B65T2G	S-80844CLMC-B65T2G	S-80844CLUA-B65T2G
		S-80844KLUA-D2AT2G*2
S-80845CLNB-B66T2G	S-80845CLMC-B66T2G	S-80845CLUA-B66T2G
S-80846CLNB-B67T2G	S-80846CLMC-B67T2G	S-80846CLUA-B67T2G
S-80847CLNB-B68T2G	S-80847CLMC-B68T2G	S-80847CLUA-B68T2G
S-80848CLNB-B69T2G	S-80848CLMC-B69T2G	S-80848CLUA-B69T2G
S-80849CLNB-B7AT2G	S-80849CLMC-B7AT2G	S-80849CLUA-B7AT2G
S-80850CLNB-B7BT2G	S-80850CLMC-B7BT2G	S-80850CLUA-B7BT2G
S-80851CLNB-B7CT2G	S-80851CLMC-B7CT2G	S-80851CLUA-B7CT2G



SC-82AB	SOT-23-5	SOT-89-3
S-80852CLNB-B7DT2G	S-80852CLMC-B7DT2G	S-80852CLUA-B7DT2G
S-80853CLNB-B7ET2G	S-80853CLMC-B7ET2G	S-80853CLUA-B7ET2G
S-80854CLNB-B7FT2G	S-80854CLMC-B7FT2G	S-80854CLUA-B7FT2G
S-80855CLNB-B7GT2G	S-80855CLMC-B7GT2G	S-80855CLUA-B7GT2G
S-80856CLNB-B7HT2G	S-80856CLMC-B7HT2G	S-80856CLUA-B7HT2G
S-80857CLNB-B7IT2G	S-80857CLMC-B7IT2G	S-80857CLUA-B7IT2G
S-80858CLNB-B7JT2G	S-80858CLMC-B7JT2G	S-80858CLUA-B7JT2G
S-80859CLNB-B7KT2G	S-80859CLMC-B7KT2G	S-80859CLUA-B7KT2G
S-80860CLNB-B7LT2G	S-80860CLMC-B7LT2G	S-80860CLUA-B7LT2G



SNT-4A	TO-92*1
S-80808CLPF-B7MTFG
S-80809CLPF-B7NTFG
S-80810CLPF-B7OTFG
S-80811CLPF-B7PTFG
S-80812CLPF-B7QTFG
S-80813CLPF-B7RTFG
S-80814CLPF-B7STFG
S-80815CLPF-B6ATFG	S-80815CLY-x-G
S-80816CLPF-B6BTFG	S-80816CLY-x-G
S-80817CLPF-B6CTFG	S-80817CLY-x-G
S-80818CLPF-B6DTFG	S-80818CLY-x-G
S-80819CLPF-B6ETFG	S-80819CLY-x-G
S-80820CLPF-B6FTFG	S-80820CLY-x-G
S-80821CLPF-B6GTFG	S-80821CLY-x-G
S-80822CLPF-B6HTFG	S-80822CLY-x-G
S-80823CLPF-B6ITFG	S-80823CLY-x-G
S-80824CLPF-B6JTFG	S-80824CLY-x-G
S-80825CLPF-B6KTFG	S-80825CLY-x-G
S-80826CLPF-B6LTFG	S-80826CLY-x-G
S-80827CLPF-B6MTFG	S-80827CLY-x-G
S-80828CLPF-B6NTFG	S-80828CLY-x-G
S-80829CLPF-B6OTFG	S-80829CLY-x-G
S-80830CLPF-B6PTFG	S-80830CLY-x-G
S-80831CLPF-B6QTFG	S-80831CLY-x-G
S-80832CLPF-B6RTFG	S-80832CLY-x-G
S-80833CLPF-B6STFG	S-80833CLY-x-G
S-80834CLPF-B6TTFG	S-80834CLY-x-G
S-80835CLPF-B6UTFG	S-80835CLY-x-G
S-80836CLPF-B6VTFG	S-80836CLY-x-G
S-80837CLPF-B6WTFG	S-80837CLY-x-G
S-80838CLPF-B6XTFG	S-80838CLY-x-G



SNT-4A	TO-92*1
S-80839CLPF-B6YTFG	S-80839CLY-x-G
S-80840CLPF-B6ZTFG	S-80840CLY-x-G
S-80841CLPF-B62TFG	S-80841CLY-x-G
S-80842CLPF-B63TFG	S-80842CLY-x-G
S-80843CLPF-B64TFG	S-80843CLY-x-G
S-80844CLPF-B65TFG	S-80844CLY-x-G
	S-80844KLY-x-G *3
S-80845CLPF-B66TFG	S-80845CLY-x-G
S-80846CLPF-B67TFG	S-80846CLY-x-G
S-80847CLPF-B68TFG	S-80847CLY-x-G
S-80848CLPF-B69TFG	S-80848CLY-x-G
S-80849CLPF-B7ATFG	S-80849CLY-x-G
S-80850CLPF-B7BTFG	S-80850CLY-x-G
S-80851CLPF-B7CTFG	S-80851CLY-x-G
S-80852CLPF-B7DTFG	S-80852CLY-x-G
S-80853CLPF-B7ETFG	S-80853CLY-x-G
S-80854CLPF-B7FTFG	S-80854CLY-x-G
S-80855CLPF-B7GTFG	S-80855CLY-x-G
S-80856CLPF-B7HTFG	S-80856CLY-x-G
S-80857CLPF-B7ITFG	S-80857CLY-x-G
S-80858CLPF-B7JTFG	S-80858CLY-x-G
S-80859CLPF-B7KTFG	S-80859CLY-x-G
S-80860CLPF-B7LTFG	S-80860CLY-x-G
