DATE - 2022/09/08
FETek_MOSFET 東沅科技股份有限公司


公司基本資料 授權代理商
東沅科技股份有限公司 汎翊國際有限公司
FETek Technology Corp. FLYING INTERNATIONAL.
新竹縣竹北市嘉豐南路一段120號 新北市三重區光復路一段80號五樓(台北科技城)
創立日期：2013年5月 創立日期：2013年2月
實收資本額：NT$ 2.21億 實收資本額：NT$ 2000萬
主要產品為高壓/中低壓的Power Mosfet Tel:02-2995-7676*222
品質管理系統認證:ISO_9001 PM:李惠雄 Jason
http://www.fetek.com.tw mail:jason.li@flying1688.com

東沅科技股份有限公司 ，設計提供給電腦、網通、消費性產品、手機、電池與其他電源相關的Power Mosfet。
主要產品為高壓/中低壓的Power Mosfet，本公司產品堅持高品質、高效率、良好、真誠的服務。

未來致力於成為台灣第一的電源管理 IC 設計公司。

東沅的Power Mosfet，效能好、可靠度佳、價格有優勢，所以在極短時間內，東沅已經擁有相當數量的客戶。
同時，東沅科技開始專注於射頻、類比晶片領域的研發和銷售，主要面向終端、基站、車載以及消費電子等市場領域。隨著業務不斷擴展和壯大，正積極拓展新興業務和市場領域， 向境內外國際知名廠商提供開關、低噪放、驅動放大器、濾波器等各類射頻器件，以及LDO、運放、時鐘、高精度AD/DA等各類模擬器件。

東沅科技於2015年1月22日通過ISO9001認證
致力於提供給客戶高品質、高滿意度、高競爭力的產品。
經多年發展及客戶支持，東沅業蹟蒸蒸日上，東沅己然成為台灣最具發展優勢Mosfet供應商；
未來，東沅將秉持著成為台灣第一大的電源管理 IC 設計公司，繼續努力！



FETek
Part No.		 ESD Package
Type		 Configuration MOSFET
Type		 VDS
(V)		 VGS
(V)		 VGS(th)
(Max.V)		 RDS(ON) (mΩ) Max. at VGS= Ciss
(pF)		 ID
(A) 		 PD
(W)
10V 4.5V 2.5V 1.8V
FKBA3002 　 PRPAK5*6 Single N 30 ±20 2.5 18 30 -------- -------- 489 35 41.7
FKBA3004 　 PRPAK5*6 Single N 30 ±20 2.5 8.5 14 -------- -------- 1317 58 46
FKBA3006 　 PRPAK5*6 Single N 30 ±20 2.5 5.5 9 -------- -------- 2295 81 59
FKBA3014 　 PRPAK5*6 Single N 30 ±20 2.5 12 18 -------- -------- 940 50 41.7
FKBA3016 　 PRPAK5*6 Single N 30 ±20 2.5 4 6 -------- -------- 3075 108 69
FKBA3018B 　 PRPAK5*6 Single N 30 ±20 2.5 2.4 3.2 -------- -------- 4345 85 187
FKBA3048 　 PRPAK5*6 Single N 30 ±20 2.2 1.6 2.5 -------- -------- 3420 100 62.5
FKBA3050 　 PRPAK5*6 Single N 30 ±20 2.5 3.8 5.8 -------- -------- 2461 75 50
FKBA3052 　 PRPAK5*6 Single N 30 ±20 2.5 6.3 9 -------- -------- 814 52 27
FKBA3054 　 PRPAK5*6 Single N 30 ±20 2.2 5.2 9 -------- -------- 1113 50 21
FKBA3056 　 PRPAK5*6 Single N 30 ±20 2.2 3.9 6.1 -------- -------- 1476 73 37.8
FKBA3058 　 PRPAK5*6 Single N 30 ±20 2.2 8 11 -------- -------- 693 30 31
FKBA3060 　 PRPAK5*6 Single N 30 ±20 2.3 9.8 15.8 -------- -------- 562 28 31
FKBA3062 　 PRPAK5*6 Single N 30 ±20 2.4 12.5 19 -------- -------- 396 40 31
FKBA3064 　 PRPAK5*6 Single N 30 ±20 2.3 2.2 3.6 -------- -------- 2917 85 48
FKBA3068 　 PRPAK5*6 Single N 30 ±20 2.5 5.5 8.5 -------- -------- 882 58 27
FKBA3072 　 PRPAK5*6 Single N 30 ±20 2.3 2 3.3 -------- -------- 2859 120 50
FKBA3080 　 PRPAK5*6 Single N 30 ±20 2.2 2.8 4.5 -------- -------- 2235 110 52
FKBA3086 　 PRPAK5*6 Single N 30 ±20 2.2 0.9 1.4 -------- -------- 7427 230 89
FKBA3086B 　 PRPAK5*6 Single N 30 ±20 2.2 1.1 1.7 -------- -------- 7427 230 89
FKBA3094 　 PRPAK5*6 Single N 30 ±20 2.2 2.2 3.6 -------- -------- 3032 85 48
FKBA8008 　 PRPAK5*6 Single N 30 ±12 1.0 4.9 5.5 7.5 -------- 3100 90 69
FKBA3202 　 PRPAK5*6 Dual N 30 ±20 2.5 18 30 -------- -------- 489 35 41.7
FKBA3204 　 PRPAK5*6 Dual N 30 ±20 2.5 8.5 14 -------- -------- 1317 35 19.2
FKBA4004 　 PRPAK5*6 Single N 40 ±20 2.5 11.5 16.5 -------- -------- 1314 46 46
FKBA4006 　 PRPAK5*6 Single N 40 ±20 2.5 7.5 10 -------- -------- 2332 60 46
FKBA4014 　 PRPAK5*6 Single N 40 ±20 2.5 17 22 -------- -------- 1013 33 31.3
FKBA4016 　 PRPAK5*6 Single N 40 ±20 2.5 6.5 9 -------- -------- 3354 75 52.1
FKBA4024A 　 PRPAK5*6 Single N 40 ±20 4 3.3 -------- -------- -------- 4711 85 83
FKBA4048 　 PRPAK5*6 Single N 40 ±20 2.2 1.8 2.6 -------- -------- 3972 100 83
FKBA4052 　 PRPAK5*6 Single N 40 ±20 3 8.5 15 -------- -------- 690 50 39
FKBA4054 　 PRPAK5*6 Single N 40 ±20 2.2 6.5 10.5 -------- -------- 1078 45 21
FKBA4064 　 PRPAK5*6 Single N 40 ±20 2.2 2.8 4 -------- -------- 2894 85 48
FKBA4070 　 PRPAK5*6 Single N 40 ±20 2.2 1.8 2.6 -------- -------- 3862 100 83
FKBA4070A 　 PRPAK5*6 Single N 40 ±20 4 1.8 -------- -------- -------- 3739 100 83
FKBA4086 　 PRPAK5*6 Single N 40 ±20 2.2 1 2 -------- -------- 6780 220 89
FKBA4086A 　 PRPAK5*6 Single N 40 ±20 4 1.1 -------- -------- -------- 6601 220 89
FKBA4094 　 PRPAK5*6 Single N 40 ±20 2.2 3.2 5.3 -------- -------- 2648 114 73.5
FKBA4204 　 PRPAK5*6 Dual N 40 ±20 2.5 15 20 -------- -------- 1314 30 20.8
FKBA4048B 　 PRPAK5*6 Single N 45 ±20 2.3 2.2 3.2 -------- -------- 3516 100 83
FKBA6006 　 PRPAK5*6 Single N 60 ±20 2.5 18 20 -------- -------- 2423 40 59
FKBA6016 　 PRPAK5*6 Single N 60 ±20 2.5 12 15 -------- -------- 3240 52 62.5
FKBA6024A 　 PRPAK5*6 Single N 60 ±20 4.5 4.8 -------- -------- -------- 5460 85 125
FKBA6032 　 PRPAK5*6 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 75 41
FKBA6040 　 PRPAK5*6 Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 116 113
FKBA6048 　 PRPAK5*6 Single N 60 ±20 2.3 3.6 5.4 -------- -------- 3458 85 83
FKBA6048A 　 PRPAK5*6 Single N 60 ±20 4 3.6 -------- -------- -------- 3509 85 83
FKBA6054 　 PRPAK5*6 Single N 60 ±20 2.3 12 18 -------- -------- 760 33 21
FKBA6056 　 PRPAK5*6 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1270 58 50
FKBA6058 　 PRPAK5*6 Single N 60 ±20 2.3 15 25 -------- -------- 512 35 31
FKBA6066 　 PRPAK5*6 Single N 60 ±20 2.3 5.2 7.8 -------- -------- 1625 80 54.3
FKBA6074 　 PRPAK5*6 Single N 60 ±20 2.3 2.1 3.2 -------- -------- 5471 100 83
FKBA6214 　 PRPAK5*6 Dual N 60 ±20 2.5 42 52 -------- -------- 1027 17 31.3
FKBA8016 　 PRPAK5*6 Single N 75 ±20 2.5 12 14.5 -------- -------- 3120 62 89
FKBA8024A 　 PRPAK5*6 Single N 80 ±20 4 6.5 -------- -------- -------- 5580 122 156
FKBA8048 　 PRPAK5*6 Single N 80 ±20 2.3 6.5 8.5 -------- -------- 2860 60 104
FKBA8066 　 PRPAK5*6 Single N 80 ±20 2.3 8.7 13 -------- -------- 1738 60 52
FKBA8074A 　 PRPAK5*6 Single N 80 ±20 4 3 -------- -------- -------- 6286 100 125
FKBA0018A 　 PRPAK5*6 Single N 100 ±20 4.5 22 -------- -------- -------- 1890 55.6 119
FKBA0020A 　 PRPAK5*6 Single N 100 ±20 4.5 13 -------- -------- -------- 2947 60 83
FKBA0024A 　 PRPAK5*6 Single N 100 ±20 4.5 10 -------- -------- -------- 5580 104 156
FKBA0036 　 PRPAK5*6 Single N 100 ±20 2.5 18.5 23.5 -------- -------- 1930 58 119
FKBA0040 　 PRPAK5*6 Single N 100 ±20 2.4 14 17 -------- -------- 4708 64 89
FKBA0048 　 PRPAK5*6 Single N 100 ±20 2.3 8 10.5 -------- -------- 3320 78 83
FKBA0048A 　 PRPAK5*6 Single N 100 ±20 4 8 -------- -------- -------- 3148 78 108
FKBA0056 　 PRPAK5*6 Single N 100 ±20 2.2 20 30 -------- -------- 849 32 37.9
FKBA0094 　 PRPAK5*6 Single N 100 ±20 2.4 11.5 15 -------- -------- 2550 60 56.5
FKBA0094A      　 PRPAK5*6 Single N 100 ±20 4 11.5 -------- -------- -------- 2422 60 56.5
FKBA15810C  　 PRPAK5*6 Single N 100 ±20 4 4.5 -------- -------- -------- 4725 100 208
FKBA90N12 　 PRPAK5*6 Single N 120 ±20 2.2 8 10 -------- -------- 3830 90 125
FKBA20N15A 　 PRPAK5*6 Single N 150 ±20 4 56 -------- -------- -------- 1190 23 75
FKBA20N15S 　 PRPAK5*6 Single N 150 ±20 2.5 56 68 -------- -------- 1090 23 72.6
FKBA0204 　 PRPAK5*6 Dual N 100 ±20 2.5 112 120 -------- -------- 1535 9.3 20.8
FKBA0256 　 PRPAK5*6 Dual N 100 ±20 2.2 20 30 -------- -------- 849 28.5 29.8
FKBA3031 　 PRPAK5*6 Single P -30 ±20 -2.5 7.2 12 -------- -------- 3450 -70 90
FKBA3103 　 PRPAK5*6 Single P -30 ±20 -2.5 20 32 -------- -------- 1345 -35 34.7
FKBA3105 　 PRPAK5*6 Single P -30 ±25 -2.5 15 25 -------- -------- 2215 -45 45
FKBA3113 　 PRPAK5*6 Single P -30 ±20 -2.5 30 55 -------- -------- 930 -31 41.7
FKBA3115 　 PRPAK5*6 Single P -30 ±25 -2.5 9.8 15 -------- -------- 3448 -59 52.1
FKBA3115E V PRPAK5*6 Single P -30 ±20 -2.5 8.5 14 -------- -------- 4319 -59 104
FKBA4115 　 PRPAK5*6 Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -52 52.1
FKBA6115 　 PRPAK5*6 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -35 52.1
FKBA0139 　 PRPAK5*6 Single P -100 ±20 -2.5 50 55 -------- -------- 6516 -8 5.5
FKBA3903 　 PRPAK5*6 Complementary N 30 ±20 2.5 18 28 -------- -------- 572 30 18.9
　 P -30 ±20 -2.5 30 55 -------- -------- 930 -24 18.9
FKBA3905 　 PRPAK5*6 Complementary N 30 ±20 2.5 12 18 -------- -------- 942 33 25
　 P -30 ±20 -2.5 18 30 -------- -------- 2213 -31 25
FKBA3430 　 PRPAK5*6 Asymmetric N 30 ±20 2.2 3.6 5.5 -------- -------- 1538 77 1.67
　 N 30 ±20 2.2 1.2 2 -------- -------- 4887 189 1.67
FKBA3496 　 PRPAK5*6 Asymmetric N 30 ±20 2.2 5.2 9 -------- -------- 1113 50 21
　 N 30 ±20 2.2 3.9 6.1 -------- -------- 1476 60 22
FKBA4400 　 PRPAK5*6 Asymmetric N 40 ±20 2.5 17 22 -------- -------- 1013 39 41
　 N 40 ±20 2.5 8.5 12 -------- -------- 2332 54 41
FKBA4810 　 PRPAK5*6 Asymmetric N 40 ±20 2.5 17 22 -------- -------- 1013 39 41
　 N 40 ±20 2.5 8.5 12 -------- -------- 2332 54 41
FKBA4903 　 PRPAK5*6 Complementary N 40 ±20 2.5 30 50 -------- -------- 593 26 35.7
　 P -40 ±20 -2.5 45 70 -------- -------- 1004 -25 35.7
FKBA4905 　 PRPAK5*6 Complementary N 40 ±20 2.5 8 10 -------- -------- 2332 15 35.7
　 P -40 ±20 -2.5 13 20 -------- -------- 3500 -15 35.7
FKBA4909 　 PRPAK5*6 Complementary N 40 ±20 2.5 8 10 -------- -------- 2332 15 35.7
　 P -40 ±20 -2.5 13 20 -------- -------- 3500 -15 35.7
FKBA6901 　 PRPAK5*6 Complementary N 60 ±20 2.5 32 38 -------- -------- 1378 23 41.6
　 P -60 ±20 -2.5 70 105 -------- -------- 1447 -18 41.6
FKBA6903 　 PRPAK5*6 Complementary N 60 ±20 2.5 45 52 -------- -------- 1027 20 41.6
　 P -60 ±20 -2.5 100 125 -------- -------- 1080 -12 41.6
FKBA0903 　 PRPAK5*6 Complementary N 100 ±20 2.5 100 125 -------- -------- 987 8 17.8
　 P -100 ±20 -2.5 220 255 -------- -------- 1228 -6.2 17.8
FKBB2722 V PRPAK3*3 Single N 20 ±12 1 -------- 2.9 3.5 5.5 4239 50 35
FKBB3002 　 PRPAK3*3 Single N 30 ±20 2.5 18 30 -------- -------- 572 28 20
FKBB3004 　 PRPAK3*3 Single N 30 ±20 2.5 9 15 -------- -------- 1317 46 29
FKBB3006 　 PRPAK3*3 Single N 30 ±20 2.5 5.5 9 -------- -------- 2295 64 35.7
FKBB3014 　 PRPAK3*3 Single N 30 ±20 2.5 12 16.5 -------- -------- 896 37 26
FKBB3016 　 PRPAK3*3 Single N 30 ±20 2.5 4 6 -------- -------- 3075 80 43.4
FKBB3046 V PRPAK3*3 Single N 30 ±20 2.5 3.8 5.8 -------- -------- 2461 40 36
FKBB3050 　 PRPAK3*3 Single N 30 ±20 2.5 3.8 5.8 -------- -------- 2461 40 26
FKBB3052 　 PRPAK3*3 Single N 30 ±20 2.5 6.3 9 -------- -------- 814 30 24
FKBB3054 　 PRPAK3*3 Single N 30 ±20 2.2 5.2 9 -------- -------- 1113 32 25
FKBB3056 　 PRPAK3*3 Single N 30 ±20 2.2 3.9 6.1 -------- -------- 1476 35 27
FKBB3058 　 PRPAK3*3 Single N 30 ±20 2.2 8 11 -------- -------- 693 28 21
FKBB3060 　 PRPAK3*3 Single N 30 ±20 2.3 9.8 15.8 -------- -------- 562 12 21
FKBB3062 　 PRPAK3*3 Single N 30 ±20 2.4 12.5 19 -------- -------- 396 36 26
FKBB3068 　 PRPAK3*3 Single N 30 ±20 2.5 5 7.5 -------- -------- 882 30 24
FKBB3072 　 PRPAK3*3 Single N 30 ±20 2.3 2.4 3.8 -------- -------- 2859 100 41.6
FKBB3080 　 PRPAK3*3 Single N 30 ±20 2.2 2.8 4.5 -------- -------- 2235 40 26
FKBB8008 　 PRPAK3*3 Single N 30 ±12 1.0 4.9 5.5 7.5 -------- 3100 50 31
FKBB4016 　 PRPAK3*3 Single N 40 ±20 2.5 6.5 9 -------- -------- 2354 40 36.7
FKBB4052 　 PRPAK3*3 Single N 40 ±20 2.5 8.5 15 -------- -------- 690 43 27.8
FKBB4054 　 PRPAK3*3 Single N 40 ±20 2.2 6.5 10.5 -------- -------- 1078 45 20.8
FKBB4062 　 PRPAK3*3 Single N 40 ±20 2.4 15 23 -------- -------- 376 33 31.3
FKBB4072 　 PRPAK3*3 Single N 40 ±20 2.2 2.7 4 -------- -------- 2643 100 41.7
FKBB4752 　 PRPAK3*3 Single N 40 ±20 2.3 3.9 6 -------- -------- 1587 50 62.5
FKBB6006 　 PRPAK3*3 Single N 60 ±20 2.5 20 24 -------- -------- 2423 33 42
FKBB6016 　 PRPAK3*3 Single N 60 ±20 2.5 12 15 -------- -------- 3240 44 42
FKBB6054 　 PRPAK3*3 Single N 60 ±20 2.3 12 18 -------- -------- 760 33 20.8
FKBB6056 　 PRPAK3*3 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1270 30 27.7
FKBB6058 　 PRPAK3*3 Single N 60 ±20 2.3 15 25 -------- -------- 512 29 20.8
FKBB6066 　 PRPAK3*3 Single N 60 ±20 2.3 5.2 7.8 -------- -------- 1625 60 44.6
FKBB6506 　 PRPAK3*3 Single N 65 ±20 2.5 17.5 22 -------- -------- 1683 35 42
FKBB6566 　 PRPAK3*3 Single N 65 ±20 2.3 5.2 7.8 -------- -------- 1625 60 44.6
FKBB0016 　 PRPAK3*3 Single N 100 ±20 2.5 47 50 -------- -------- 3848 20 52.1
FKBE2730 V PRPAK3*3 Dual N 20 ±12 1.2 -------- 17 27 -------- 735 7 1.47
FKBE2738 V PRPAK3*3 Dual N 20 ±12 1.2 -------- 10.5 15 -------- 1660 12 2
FKBB3202 　 PRPAK3*3 Dual N 30 ±20 2.5 18 30 -------- -------- 572 28 20.8
FKBB3214 　 PRPAK3*3 Dual N 30 ±20 2.5 14 19.5 -------- -------- 896 25 26
FKBB6214 　 PRPAK3*3 Dual N 60 ±20 2.5 42 52 -------- -------- 1027 16 20.8
FKBB6254 　 PRPAK3*3 Dual N 60 ±20 2.3 15 21 -------- -------- 760 29 20.8
FKBB0208 　 PRPAK3*3 Dual N 100 ±20 3 330 360 -------- -------- 508 4.6 15.6
FKBB0210 　 PRPAK3*3 Dual N 100 ±20 2.3 100 130 -------- -------- 180 8 1.5
FKBB0214 　 PRPAK3*3 Dual N 100 ±20 2.5 152 158 -------- -------- 1077 8 1.67
FKBB2627 　 PRPAK3*3 Single P -20 ±12 -1.0 -------- 9 11.5 15 5783 -48 29
FKBB3103 　 PRPAK3*3 Single P -30 ±25 -2.5 20 32 -------- -------- 1345 -32 29
FKBB3105 　 PRPAK3*3 Single P -30 ±20 -2.5 14 22 -------- -------- 2215 -42 37
FKBB3115 　 PRPAK3*3 Single P -30 ±20 -2.5 8.7 13.5 -------- -------- 3448 -50 69
FKBB3115E V PRPAK3*3 Single P -30 ±20 -2.5 8.5 14 -------- -------- 4319 -32 96
FKBB3151 　 PRPAK3*3 Single P -30 ±20 -2.3 9.5 16 -------- -------- 3614 -50 50
FKBB4113 　 PRPAK3*3 Single P -40 ±20 -2.5 40 65 -------- -------- 1004 -15 31.3
FKBB4115 　 PRPAK3*3 Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -40 31.3
FKBB6113 　 PRPAK3*3 Single P -60 ±20 -2.5 90 132 -------- -------- 1080 -13 31.3
FKBB6115 　 PRPAK3*3 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -26 31.25
FKBB02P15 　 PRPAK3*3 Single P -150 ±20 -4 780 980 -------- -------- 706 -2 7.8
FKBB3313 　 PRPAK3*3 Dual P -30 ±20 -2.5 40 62 -------- -------- 930 -19 20.8
FKBB3901 　 PRPAK3*3 Complementary N 30 ±20 2.5 34 50 -------- -------- 416 19 20.8
　 P -30 ±20 -2.5 36 60 -------- -------- 930 -18.7 20.8
FKBB3909 　 PRPAK3*3 Complementary N 30 ±20 2.5 20 30 -------- -------- 572 24 20
　 P -30 ±20 -2.5 18 30 -------- -------- 2213 -27 20
FKBB6903 　 PRPAK3*3 Complementary N 60 ±20 2.5 50 70 -------- -------- 1027 5 2
　 P -60 ±20 -2.5 100 120 -------- -------- 1447 -3.8 2
FKBB0903 　 PRPAK3*3 Complementary N 100 ±20 2.7 100 125 -------- -------- 987 6 1.5
　 P -100 ±20 -2.5 220 255 -------- -------- 1228 -4.1 1.5
FKBE3901 　 PRPAK3*3
NEP		 Complementary N 30 ±20 2.5 28 40 -------- -------- 416 7 2.5
　 P -30 ±20 -2.5 32 56 -------- -------- 930 -7 2.5
FKBE3903 　 PRPAK3*3
NEP		 Complementary N 30 ±20 2.5 18 28 -------- -------- 572 10 2.6
　 P -30 ±20 -2.5 30 55 -------- -------- 930 -8 2.6
FKBE3911 　 PRPAK3*3
NEP		 Complementary N 30 ±20 2.5 35 55 -------- -------- 416 6 1.5
　 P -30 ±20 -2.5 50 80 -------- -------- 585 -4.9 1.5
FKBE0901 　 PRPAK3*3
NEP		 Complementary N 100 ±20 2.5 310 320 -------- -------- 508 2 1.5
　 P -100 ±20 -2.5 650 700 -------- -------- 553 1.5 1.5
FKCA1002 V DFN3*3 Dual N 12 ±8 1.0 -------- 4.3 5.6 7.6 3165 56 31
FKCA1030 V DFN3*3 Dual N 12 ±8 1.0 -------- 4.3 5.6 7.6 3165 56 31
FKCA2030 V DFN3*3 Dual N 20 ±8 1.0 -------- 5.8 7 12 3165 56 31
FKCA3214 　 DFN3*3 Dual N 30 ±20 2.5 12 15 -------- -------- 940 30 1.9
FKCB2903 　 DFN2*2 Complementary N 20 ±12 1.0 -------- 40 55 70 310 5 1.56
　 P -20 ±12 -1.0 -------- 100 145 200 677 -4.5 1.56
FKCB8236 V DFN2*2 Dual N 20 ±12 1.5 -------- 22 29 -------- 630 6 1.4
FKCC2734 V DFN2*3 Dual N 20 ±12 1.2 -------- 16 27.5 -------- 735 8 1.56
FKCC8204 V DFN2*3 Dual N 20 ±12 1.2 -------- 9 13.5 -------- 1647 9.5 1.56
FKCC8211 V DFN2*3 Dual N 20 ±12 1.2 -------- 13 20 -------- 734 8 1.56
FKCC8233 V DFN2*3 Dual N 20 ±12 1.5 -------- 7.2 10.2 -------- 1767 11 1.56
FKCD3014 　 DFN2*2 Single N 30 ±20 2.5 12 16.5 -------- -------- 896 37 26
FKCD3113 　 DFN2*2 Single P -30 ±20 -2.5 32 53 -------- -------- 930 -8 2.8
FKCE2530 V DFN3.3*3.3 Single N 20 ±12 1.0 -------- 2 2.7 -------- 4307 50 83
FKCE2631 　 DFN3.3*3.3 Single P -20 ±12 -1.0 -------- 5 6.5 8.5 4307 -50 83
FKCE6032 　 DFN3.3*3.3 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 50 41
FKCE3031 　 DFN3.3*3.3 Single P -30 ±20 -2.5 7.2 12 -------- -------- 3450 -50 41
FKCE8016 　 DFN3.3*3.3 Single N 75 ±20 2.5 12 14.5 -------- -------- 3120 45 41
FKCS2050 V CSP Dual N 20 ±12 1.2 -------- 36 55 -------- ------ 6 1.6
FKCS2052 V CSP Dual N 24 ±12 1.2 -------- 45 70 -------- ------ 6 1.6
FKD3002 　 TO252 Single N 30 ±20 2.5 18 30 -------- -------- 572 30 25
FKD3004 　 TO252 Single N 30 ±20 2.5 8.5 14 -------- -------- 1317 55 41
FKD3004S 　 TO252 Single N 30 ±20 2.2 8 11 -------- -------- 693 52 34.7
FKD3006 　 TO252 Single N 30 ±20 2.5 5.5 9 -------- -------- 2295 80 53
FKD3006S 　 TO252 Single N 30 ±20 2.5 5.8 8.5 -------- -------- 882 78 50
FKD3008 　 TO252 Single N 30 ±20 2.5 25 38 -------- -------- 416 24 20.8
FKD3014 　 TO252 Single N 30 ±20 2.5 12 18 -------- -------- 940 43 37.5
FKD3016 　 TO252 Single N 30 ±20 2.5 4 6 -------- -------- 3075 96 62.5
FKD3018B 　 TO252 Single N 30 ±20 2.5 2.4 3.2 -------- -------- 4345 70 60
FKD3058 　 TO252 Single N 30 ±20 2.2 8 11 -------- -------- 693 52 34.7
FKD3068 　 TO252 Single N 30 ±20 2.5 5.8 8.5 -------- -------- 882 78 50
FKD3078 　 TO252 Single N 30 ±20 2.2 5.5 9 -------- -------- 1907 72 45
FKD4002 　 TO252 Single N 40 ±20 2.5 26 35 -------- -------- 593 23 25
FKD4004 　 TO252 Single N 40 ±20 2.5 11.5 16.5 -------- -------- 1314 42 34.7
FKD4006 　 TO252 Single N 40 ±20 2.5 7.5 10 -------- -------- 2332 60 44.6
FKD4014 　 TO252 Single N 40 ±20 2.5 17 22 -------- -------- 1013 33 31.3
FKD4016 　 TO252 Single N 40 ±20 2.5 6.5 9 -------- -------- 3354 75 52.1
FKD4024A 　 TO252 Single N 40 ±20 4 3.3 -------- -------- -------- 4711 70 125
FKD4048 　 TO252 Single N 40 ±20 2.2 2.4 3.6 -------- -------- 3972 100 125
FKD4058 　 TO252 Single N 40 ±20 2.2 9 14 -------- -------- 669 46 31
FKD4094 　 TO252 Single N 40 ±20 2.2 3.2 5.3 -------- -------- 2648 114 73.5
FKD4048B 　 TO252 Single N 45 ±20 2.3 2.2 3.2 -------- -------- 3516 100 83
FKD4070A 　 TO252 Single N 40 ±20 3.6 2.6 -------- -------- -------- 3739 100 83
FKD6002 　 TO252 Single N 60 ±20 2.5 75 90 -------- -------- 695 17 42
FKD6002A 　 TO252 Single N 60 ±20 2.5 70 90 -------- -------- 695 17 42
FKD6004 　 TO252 Single N 60 ±20 2.5 30 38 -------- -------- 1378 23 34.7
FKD6006 　 TO252 Single N 60 ±20 2.5 20 24 -------- -------- 2423 35 45
FKD6008 　 TO252 Single N 60 ±20 2.5 90 100 -------- -------- 511 10 20.8
FKD6014 　 TO252 Single N 60 ±20 2.5 40 50 -------- -------- 1027 20 31.3
FKD6016 　 TO252 Single N 60 ±20 2.5 12 15 -------- -------- 3240 47 52
FKD6016A 　 TO252 Single N 60 ±20 5 12 -------- -------- -------- 2186 47 52
FKD6018A 　 TO252 Single N 60 ±20 4.5 8.2 -------- -------- -------- 1990 76 89.3
FKD6032 　 TO252 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 75 41
FKD6032A 　 TO252 Single N 60 ±20 4.5 8.5 -------- -------- -------- 3307 75 41
FKD6040  　 TO252 Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 112 104
FKD6056 　 TO252 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1270 58 52
FKD8014 　 TO252 Single N 80 ±20 2.5 100 115 -------- -------- 1090 11.8 31.3
FKD8016 　 TO252 Single N 75 ±20 2.5 12 14.5 -------- -------- 3120 62 89
FKD8048 　 TO252 Single N 80 ±20 2.3 6.5 8.5 -------- -------- 2860 48 56
FKD8066 　 TO252 Single N 80 ±20 2.3 8.7 12.5 -------- -------- 1738 60 52
FKD0004 　 TO252 Single N 100 ±20 2.5 112 120 -------- -------- 1535 12 34.7
FKD0008 　 TO252 Single N 100 ±20 2.5 310 320 -------- -------- 508 5.4 20.8
FKD0014 　 TO252 Single N 100 ±20 2.5 152 158 -------- -------- 1077 11 31
FKD0016 　 TO252 Single N 100 ±20 2.5 47 50 -------- -------- 3848 22 52.1
FKD0016A 　 TO252 Single N 100 ±20 4 47 -------- -------- -------- 3848 24 54
FKD0018A 　 TO252 Single N 100 ±20 4.5 22 -------- -------- -------- 1890 45 90
FKD0020A 　 TO252 Single N 100 ±20 4.5 13.5 -------- -------- -------- 2947 56 83
FKD0026 　 TO252 Single N 100 ±20 2.5 22 28 -------- -------- 1930 40 62.5
FKD0028 　 TO252 Single N 100 ±20 2.9 66 85 -------- -------- 620 14 30
FKD0032 　 TO252 Single N 100 ±20 2.5 26 32 -------- -------- 3307 30 52
FKD0034 　 TO252 Single N 100 ±20 2.9 100 110 -------- -------- 1009 14.6 30
FKD0040 　 TO252 Single N 100 ±20 2.4 14 17 -------- -------- 4708 64 89
FKD0048 　 TO252 Single N 100 ±20 2.3 8.5 11 -------- -------- 3320 73 108
FKD0094 　 TO252 Single N 100 ±20 2.4 11.5 15 -------- -------- 2550 58 73
FKD15810C 　 TO252 Single N 100 ±20 4 4.5 -------- -------- -------- 4725 112 104
FKD48N12A 　 TO252 Single N 120 ±20 4 30 -------- -------- -------- 1362 48 113
FKD20N15 　 TO252 Single N 150 ±20 2.5 88 100 -------- -------- 2285 20 72.6
FKD20N15A 　 TO252 Single N 150 ±20 4 56 -------- -------- -------- 1190 23 72.6
FKD20N15S 　 TO252 Single N 150 ±20 2.5 56 68 -------- -------- 1090 23 72.6
FKD28N15 　 TO252 Single N 150 ±20 2.5 46 50 -------- -------- 3755 30 115
FKD18N20 　 TO252 Single N 200 ±20 2.5 170 180 -------- -------- 2047 18 83
FKD3031 　 TO252 Single P -30 ±20 -2.5 7.2 12 -------- -------- 3450 -70 90
FKD3101 　 TO252 Single P -30 ±20 -2.5 42 78 -------- -------- 585 -20 25
FKD3103 　 TO252 Single P -30 ±20 -2.5 20 32 -------- -------- 1345 -35 34.7
FKD3105 　 TO252 Single P -30 ±25 -2.5 15 25 -------- -------- 2215 -45 45
FKD3107 　 TO252 Single P -30 ±20 -2.5 62 110 -------- -------- 463 -15.4 20.8
FKD3113 　 TO252 Single P -30 ±20 -2.5 30 55 -------- -------- 930 -27 31.3
FKD3115 　 TO252 Single P -30 ±25 -2.5 10.5 18.5 -------- -------- 3448 -57 52.1
FKD4101 　 TO252 Single P -40 ±20 -2.5 65 100 -------- -------- 620 -16 25
FKD4103 　 TO252 Single P -40 ±20 -2.5 32 46 -------- -------- 1415 -27 35
FKD4113 　 TO252 Single P -40 ±20 -2.5 40 65 -------- -------- 1004 -23 31.3
FKD4115 　 TO252 Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -52 52.1
FKD6101 　 TO252 Single P -60 ±20 -2.5 140 190 -------- -------- 715 -12 25
FKD6103 　 TO252 Single P -60 ±20 -2.5 70 105 -------- -------- 1447 -18 34.7
FKD6105 　 TO252 Single P -60 ±20 -2.5 35 55 -------- -------- 2217 -29 2
FKD6107 　 TO252 Single P -60 ±20 -2.5 180 266 -------- -------- 531 -8 20.8
FKD6113 　 TO252 Single P -60 ±20 -2.5 90 115 -------- -------- 1080 -13 31.3
FKD6115 　 TO252 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -35 52.1
FKD0103 　 TO252 Single P -100 ±20 -2.5 210 240 -------- -------- 1228 -8.7 2
FKD0107 　 TO252 Single P -100 ±20 -2.5 650 700 -------- -------- 553 -4.1 20.8
FKD0115 　 TO252 Single P -100 ±20 -2.5 95 110 -------- -------- 3029 -18 54
FKD0139 　 TO252 Single P -100 ±20 -2.5 50 55 -------- -------- 6516 -30 104
FKD3901 　 TO252-4L Complementary N 30 ±20 2.5 27 40 -------- -------- 416 24 20.8
　 P -30 ±20 -2.5 32 56 -------- -------- 930 -22 20.8
FKD3903 　 TO252-4L Complementary N 30 ±20 2.5 18 28 -------- -------- 572 30 25
　 P -30 ±20 -2.5 30 55 -------- -------- 930 -24 25
FKD4903 　 TO252-4L Complementary N 40 ±20 2.5 28 42 -------- -------- 593 23 25
　 P -40 ±20 -2.5 40 65 -------- -------- 1004 -20 31.3
FKD6901 　 TO252-4L Complementary N 60 ±20 2.5 32 38 -------- -------- 1378 23 34.7
　 P -60 ±20 -2.5 70 105 -------- -------- 1447 -18 34.7
FKD6903 　 TO252-4L Complementary N 60 ±20 2.5 40 50 -------- -------- 1027 20 50
　 P -60 ±20 -2.5 100 125 -------- -------- 1080 -12 50
FKD0903 　 TO252-4L Complementary N 100 ±20 2.5 100 125 -------- -------- 987 8 1.5
　 P -100 ±20 -2.5 220 255 -------- -------- 1228 -6.2 1.5
FKF4048 　 TO220F Single N 40 ±20 2.2 3.2 4.3 -------- -------- 3972 88 41.6
FKF6004 　 TO220F Single N 60 ±20 2.5 30 38 -------- -------- 1378 20 23
FKF6006 　 TO220F Single N 60 ±20 2.5 20 24 -------- -------- 2423 30 30
FKF6016 　 TO220F Single N 60 ±20 2.5 12 15 -------- -------- 3240 38 34.7
FKF6040 　 TO220F Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 67 41.9
FKF6048 　 TO220F Single N 60 ±20 2.3 4.5 6.5 -------- -------- 3458 80 54.3
FKF6066 　 TO220F Single N 60 ±20 2.3 6 9 -------- -------- 1625 54 31.3
FKF0016 　 TO220F Single N 100 ±20 2.5 47 50 -------- -------- 3848 17.5 34.7
FKF0018A 　 TO220F Single N 100 ±20 4.5 22 -------- -------- -------- 1890 27 42
FKF0024A 　 TO220F Single N 100 ±20 4.5 12 -------- -------- -------- 5580 60 40
FKF0048 　 TO220F Single N 100 ±20 2.3 8 10.5 -------- -------- 3320 48 108
FKF0048A 　 TO220F Single N 100 ±20 4 8 -------- -------- -------- 3148 52 37.5
FKF0094 　 TO220F Single N 100 ±20 2.4 12 15 -------- -------- 3150 36 56.5
FKF0094A 　 TO220F Single N 100 ±20 4 11.5 -------- -------- -------- 2422 50 52
FKF15810C 　 TO220F Single N 100 ±20 4 4.5 -------- -------- -------- 4725 70 41.6
FKF4115 　 TO220F Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -41 34.7
FKF6103 　 TO220F Single P -60 ±20 -2.5 70 105 -------- -------- 1447 -15 23
FKH3004 　 TO263 Single N 30 ±20 2.5 8.5 14 -------- -------- 1317 65 58
FKH3006 　 TO263 Single N 30 ±20 2.5 6 9 -------- -------- 2295 90 74
FKH3018B 　 TO263 Single N 30 ±20 2.5 2.4 3.2 -------- -------- 5850 205 187
FKH4024A 　 TO263 Single N 40 ±20 4.5 3.3 -------- -------- -------- 4711 165 149
FKH4048 　 TO263 Single N 40 ±20 2.2 2.8 3.6 -------- -------- 3972 170 178
FKH4070 　 TO263 Single N 40 ±20 2.2 2.6 3.6 -------- -------- 3862 170 178
FKH4070A 　 TO263 Single N 40 ±20 4 2.8 -------- -------- -------- 3739 170 178
FKH6006 　 TO263 Single N 60 ±20 2.5 20 24 -------- -------- 2423 45 74
FKH6018A 　 TO263 Single N 60 ±20 4.5 8.2 -------- -------- -------- 1990 98 149
FKH6024A 　 TO263 Single N 60 ±20 4.5 4.8 -------- -------- -------- 5580 160 214
FKH6032 　 TO263 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 80 41
FKH6040 　 TO263 Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 140 166
FKH6048 　 TO263 Single N 60 ±20 2.3 4.5 6.5 -------- -------- 3458 110 113
FKH8016 　 TO263 Single N 75 ±20 2.5 12 14.5 -------- -------- 3120 80 125
FKH8024A 　 TO263 Single N 80 ±20 4.5 6.5 -------- -------- -------- 5580 108 149
FKH8048 　 TO263 Single N 80 ±20 2.3 6.5 9 -------- -------- 2860 120 150
FKH8448 　 TO263 Single N 80 ±20 2.3 3.4 4.5 -------- -------- 6304 180 272
FKH0016 　 TO263 Single N 100 ±20 2.5 40 50 -------- -------- 2270 36 125
FKH0018A 　 TO263 Single N 100 ±20 4.5 22 -------- -------- -------- 1890 58 149
FKH0024A 　 TO263 Single N 100 ±20 4.5 12 -------- -------- -------- 5580 104 156
FKH0026 　 TO263 Single N 100 ±20 2.5 22 28 -------- -------- 1930 40 62.5
FKH0048 　 TO263 Single N 100 ±20 2.3 8 10.5 -------- -------- 3320 85 125
FKH0048A 　 TO263 Single N 100 ±20 4 8 -------- -------- -------- 3148 85 125
FKH0076A 　 TO263 Single N 100 ±20 4 2.2 -------- -------- -------- 13362 308 429
FKH15810C 　 TO263 Single N 100 ±20 4 4.5 -------- -------- -------- 4725 120 250
FKH100N12 　 TO263 Single N 120 ±20 4 6.2 -------- -------- -------- 6494 100 178
FKH100N15 　 TO263 Single N 150 ±20 4 9 -------- -------- -------- 5870 100 178
FKH18N20 　 TO263 Single N 200 ±20 2.5 170 180 -------- -------- 2047 18 83
FKH6115 　 TO263 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -45 86.8
FKH0139 　 TO263 Single P -100 ±20 -2.5 50 55 -------- -------- 6516 -35 104
FKK3002 　 SOT89 Single N 30 ±20 2.5 28 40 -------- -------- 572 5.8 1.5
FKK4008 　 SOT89 Single N 40 ±20 2.5 40 55 -------- -------- 452 6 1.47
FKK6008 　 SOT89 Single N 60 ±20 2.5 100 110 -------- -------- 511 2.8 1.5
FKK6014 　 SOT89 Single N 60 ±20 2.5 50 60 -------- -------- 1027 5 2
FKK0008 　 SOT89 Single N 100 ±20 2.5 310 320 -------- -------- 508 2.2 1.5
FKK0014 　 SOT89 Single N 100 ±20 2.5 160 170 -------- -------- 1077 3 1.5
FKK3101 　 SOT89 Single P -30 ±20 -2.5 52 90 -------- -------- 583 -4 1.32
FKK3103 　 SOT89 Single P -30 ±20 -2.5 32 45 -------- -------- 1345 -5.8 1.5
FKK3107 　 SOT89 Single P -30 ±20 -2.5 70 120 -------- -------- 463 -3.9 1.5
FKK3113 　 SOT89 Single P -30 ±20 -2.5 40 62 -------- -------- 1100 -5 1.5
FKK4101 　 SOT89 Single P -40 ±20 -2.5 70 100 -------- -------- 620 -5.8 1.4
FKL3002 　 SOT223 Single N 30 ±20 2.5 28 40 -------- -------- 572 5.8 1.5
FKL6008 　 SOT223 Single N 60 ±20 2.5 100 110 -------- -------- 511 2.8 1.5
FKL6014 　 SOT223 Single N 60 ±20 2.5 50 60 -------- -------- 1027 5 2.7
FKL0004 　 SOT223 Single N 100 ±20 2.5 112 120 -------- -------- 1535 2.5 1.5
FKL0006 　 SOT223 Single N 100 ±20 2.5 75 82 -------- -------- 2400 3 2
FKL0008 　 SOT223 Single N 100 ±20 2.5 310 320 -------- -------- 510 2.2 1.5
FKL0016 　 SOT223 Single N 100 ±20 2.5 47 50 -------- -------- 3848 6 1.5
FKL0034 　 SOT223 Single N 100 ±20 2.5 100 120 -------- -------- 450 3.3 2.2
FKL03N20 　 SOT223 Single N 200 ±20 3 1000 1100 -------- -------- 900 1.5 42
FKL3101 　 SOT223 Single P -30 ±20 -2.5 52 90 -------- -------- 583 -4.5 1.5
FKL3103 　 SOT223 Single P -30 ±20 -2.5 32 45 -------- -------- 1345 -5.8 1.5
FKL3107 　 SOT223 Single P -30 ±20 -2.5 70 120 -------- -------- 463 -3.9 1.5
FKL6101 　 SOT223 Single P -60 ±20 -2.5 130 190 -------- -------- 715 -4.3 2
FKL6107 　 SOT223 Single P -60 ±20 -2.5 180 260 -------- -------- 428 -2.3 1.5
FKL0107 　 SOT223 Single P -100 ±20 -2.5 650 700 -------- -------- 553 -1.5 1.5
FKN2510 　 SOT23 Single N 20 ±12 1.0 -------- 26 35 50 670 6 1
FKN2544 　 SOT23 Single N 20 ±12 1.2 -------- 55 75 -------- 310 3.6 1
FKN3002 　 SOT23 Single N 30 ±20 2.5 28 40 -------- -------- 572 5 1
FKN3008 　 SOT23 Single N 30 ±20 2.5 33 50 -------- -------- 420 4.6 1
FKN3502 　 SOT23 Single N 30 ±12 1.2 27 32 40 -------- 860 5.8 1
FKN3504 　 SOT23 Single N 30 ±12 1.2 -------- 40 47 -------- 662 3.9 1
FKN4002 　 SOT23 Single N 40 ±20 2.5 32 45 -------- -------- 593 5 1.25
FKN4008 　 SOT23 Single N 40 ±20 2.5 37 50 -------- -------- 452 4.5 1
FKN6008 　 SOT23 Single N 60 ±20 2.5 100 110 -------- -------- 511 2.3 1
FKN6014 　 SOT23 Single N 60 ±20 2.5 50 60 -------- -------- 1028 5 2.7
FKN0008 　 SOT23 Single N 100 ±20 2.5 310 320 -------- -------- 508 1.2 1
FKN0010 　 SOT23 Single N 100 ±20 2.3 120 150 -------- -------- 180 2.1 1
FKN0014 　 SOT23 Single N 100 ±20 2.5 160 175 -------- -------- 1077 2 1.5
FKN2601 　 SOT23 Single P -20 ±12 -1.2 -------- 60 90 -------- 857 -3.4 1
FKN2607 　 SOT23 Single P -20 ±12 -1.0 -------- 32 40 55 2280 -4.7 1
FKN2609 　 SOT23 Single P -20 ±12 -1.2 -------- 75 105 -------- 686 -3.1 1
FKN2611 　 SOT23 Single P -20 ±12 -1.0 -------- 45 60 85 857 -4.9 1.31
FKN2643 　 SOT23 Single P -20 ±12 -1.0 -------- 100 120 -------- 677 -3 1
FKN3101 　 SOT23 Single P -30 ±20 -2.5 52 90 -------- -------- 583 -3.3 1
FKN3103 　 SOT23 Single P -30 ±20 -2.5 32 45 -------- -------- 942 -4.8 1
FKN3107 　 SOT23 Single P -30 ±20 -2.5 70 120 -------- -------- 463 -3.2 1
FKN3113 　 SOT23 Single P -30 ±20 -2.5 40 62 -------- -------- 930 -4.2 1
FKN3601 　 SOT23 Single P -30 ±12 -1.2 53 60 80 -------- 920 -4.3 1.4
FKN3603 　 SOT23 Single P -30 ±12 -1.2 60 80 120 200 750 -3.2 1.38
FKN4101 　 SOT23 Single P -40 ±20 -2.5 70 100 -------- -------- 620 -3.2 1
FKN6107 　 SOT23 Single P -60 ±20 -2.5 180 266 -------- -------- 531 -1.7 1
FKN0107 　 SOT23 Single P -100 ±20 -2.5 650 700 -------- -------- 553 -0.9 1
FKO2702 　 TSSOP8 Dual N 20 ±12 1.0 -------- 30 35 43 670 4.5 1
FKO2726 V TSSOP8 Dual N 20 ±12 1.2 -------- 14.5 23 -------- 850 7 2
FKO2732 V TSSOP8 Dual N 20 ±12 1.2 -------- 18.5 28.5 -------- 865 7 1.5
FKO2742 V TSSOP8 Dual N 20 ±12 1.2 -------- 25 40 -------- 863 6 1.5
FKP3002 　 TO220 Single N 30 ±20 2.5 18 30 -------- -------- 572 37 41
FKP3006 　 TO220 Single N 30 ±20 2.5 6 9 -------- -------- 2295 90 74
FKP3014 　 TO220 Single N 30 ±20 2.5 12 18 -------- -------- 940 53 52.1
FKP3016 　 TO220 Single N 30 ±20 2.5 4 6 -------- -------- 3075 110 86.8
FKP3018B 　 TO220 Single N 30 ±20 2.5 2.7 3.8 -------- -------- 5850 205 187
FKP3018R 　 TO220 Single N 30 ±20 2.5 3 4 -------- -------- 5935 182 149
FKP4016 　 TO220 Single N 40 ±20 2.5 6.5 8.5 -------- -------- 3415 90 87
FKP4024A 　 TO220 Single N 40 ±20 4.5 3.3 -------- -------- -------- 4711 167 149
FKP4048 　 TO220 Single N 40 ±20 2.2 2.6 3.6 -------- -------- 3972 170 178
FKP4070 　 TO220 Single N 40 ±20 2.2 2.6 3.6 -------- -------- 3862 170 178
FKP4070A 　 TO220 Single N 40 ±20 4 2.8 -------- -------- -------- 3739 170 178
FKP4086 　 TO220 Single N 40 ±20 2.3 1.9 2.6 -------- -------- 6780 220 149
FKP4086A 　 TO220 Single N 40 ±20 4 1.9 -------- -------- -------- 6601 220 149
FKP4094 　 TO220 Single N 40 ±20 2.2 3.8 5.3 -------- -------- 2648 105 73.5
FKP6004 　 TO220 Single N 60 ±20 2.5 30 38 -------- -------- 1378 30 58
FKP6006 　 TO220 Single N 60 ±20 2.5 20 24 -------- -------- 2423 45 74
FKP6008 　 TO220 Single N 60 ±20 2.5 90 100 -------- -------- 511 14 34.7
FKP6014 　 TO220 Single N 60 ±20 2.5 40 50 -------- -------- 1027 26 52.1
FKP6016 　 TO220 Single N 60 ±20 2.5 12 15 -------- -------- 3240 60 86.8
FKP6016A 　 TO220 Single N 60 ±20 5 12 -------- -------- -------- 2186 60 86.8
FKP6018A 　 TO220 Single N 60 ±20 4.5 8.2 -------- -------- -------- 1990 98 149
FKP6024A 　 TO220 Single N 60 ±20 4.5 4.8 -------- -------- -------- 5580 170 260
FKP6032A 　 TO220 Single N 60 ±20 4.5 8.5 -------- -------- -------- 3307 75 89
FKP6040 　 TO220 Single N 60 ±20 2.5 6.5 8.5 -------- -------- 4706 85 267
FKP6048 　 TO220 Single N 60 ±20 2.3 4.5 6.5 -------- -------- 3458 120 136
FKP6048A 　 TO220 Single N 60 ±20 4 4.8 -------- -------- -------- 3509 115 136
FKP6056 　 TO220 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1270 63 62.5
FKP6074 　 TO220 Single N 60 ±20 2.3 2.8 4 -------- -------- 5471 185 178
FKP8016 　 TO220 Single N 80 ±20 2.5 12 14.5 -------- -------- 3120 100 89
FKP8024A 　 TO220 Single N 80 ±20 4 6.5 -------- -------- -------- 5580 108 149
FKP8048 　 TO220 Single N 80 ±20 2.3 6.5 9 -------- -------- 2860 120 150
FKP8048A 　 TO220 Single N 80 ±20 4 6.5 -------- -------- -------- 3109 120 150
FKP8074A 　 TO220 Single N 80 ±20 4 3.5 -------- -------- -------- 6286 174 178
FKP0004 　 TO220 Single N 100 ±20 2.5 112 120 -------- -------- 1535 18 59
FKP0014 　 TO220 Single N 100 ±20 2.5 152 158 -------- -------- 1077 11.8 52.1
FKP0016 　 TO220 Single N 100 ±20 2.5 47 50 -------- -------- 3848 27 87
FKP0016A 　 TO220 Single N 100 ±20 4 47 -------- -------- -------- 3848 37 87
FKP0018A 　 TO220 Single N 100 ±20 4.5 22 -------- -------- -------- 1890 58 149
FKP0020A 　 TO220 Single N 100 ±20 4.5 14 --------- -------- -------- 2947 70 83
FKP0024A 　 TO220 Single N 100 ±20 4.5 12 -------- -------- -------- 5580 104 156
FKP0048 　 TO220 Single N 100 ±20 2.3 9 12 -------- -------- 3320 80 188
FKP0070 　 TO220 Single N 100 ±20 2.3 8 10 -------- -------- 2377 77 83
FKP0076A 　 TO220 Single N 100 ±20 4 2.2 -------- -------- -------- 13362 308 429
FKP0094 　 TO220 Single N 100 ±20 2.3 11.5 15 -------- -------- 2550 75 104
FKP0094A 　 TO220 Single N 100 ±20 4 11.5 -------- -------- -------- 2206 60 62.5
FKP90N12 　 TO220 Single N 120 ±20 2.2 8 10 -------- -------- 3830 90 178
FKP100N12 　 TO220 Single N 120 ±20 4 6.2 -------- -------- -------- 6494 100 178
FKP100N15 　 TO220 Single N 150 ±20 4 9 -------- -------- -------- 5870 100 178
FKP18N20 　 TO220 Single N 200 ±20 2.5 170 180 -------- -------- 2047 18 83
FKP3105 　 TO220 Single P -30 ±20 -2.5 14 22 -------- -------- 2215 -60 74
FKP3115 　 TO220 Single P -30 ±20 -2.5 10.5 18.5 -------- -------- 3448 -74 86.8
FKP4115 　 TO220 Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -54 62.5
FKP6103 　 TO220 Single P -60 ±20 -2.5 70 105 -------- -------- 1447 -23 58
FKP6105 　 TO220 Single P -60 ±20 -2.5 35 55 -------- -------- 2217 -40 83
FKP6113 　 TO220 Single P -60 ±20 -2.5 90 132 -------- -------- 1080 -17 52.1
FKP6115 　 TO220 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -45 86.8
FKP0115 　 TO220 Single P -100 ±20 -2.5 95 110 -------- -------- 3029 -23 96
FKP0139 　 TO220 Single P -100 ±20 -2.5 50 55 -------- -------- 6516 -35 104
FKQ2510 　 TSOP6 Single N 20 ±12 1.2 -------- 37 45 -------- 635 4.5 1.1
FKQ2720 V TSOP6 Dual N 20 ±12 1.2 -------- 20 26 -------- 630 6 1.25
FKQ2721 V TSOP6 Dual N 20 ±12 1.2 -------- 23.5 35.5 -------- 635 5.5 1.25
FKQ2724 V TSOP6 Dual N 20 ±12 1.2 -------- 17 24.5 -------- 523 7 1.25
FKQ2728 V TSOP6 Dual N 20 ±12 1.2 -------- 24.5 33 -------- 638 6 1.25
FKQ8205 V TSOP6 Dual N 20 ±12 1.2 -------- 27.5 38 -------- 636 5 1.25
FKQ3002 　 TSOP6 Single N 30 ±20 2.5 28 40 -------- -------- 572 5 1.1
FKQ3014 　 TSOP6 Single N 30 ±20 2.5 12.5 18 -------- -------- 940 8 2.1
FKQ3208 　 TSOP6 Dual N 30 ±20 2.5 33 50 -------- -------- 420 4.6 1
FKQ3706 　 TSOP6 Dual N 30 ±12 1.2 60 65 85 -------- 662 3.8 1.1
FKQ6008 　 TSOP6 Single N 60 ±20 2.5 100 110 -------- -------- 511 2.3 1
FKQ6208 　 TSOP6 Dual N 60 ±20 2.5 100 110 -------- -------- 511 2.5 1.1
FKQ0208 　 TSOP6 Dual N 100 ±20 2.5 310 320 -------- -------- 508 1.2 1
FKQ2607 　 TSOP6 Single P -20 ±12 -1.0 -------- 30 38 55 2280 -6.9 1
FKQ3101 　 TSOP6 Single P -30 ±20 -2.5 52 83 -------- -------- 583 -5 1.9
FKQ3113 　 TSOP6 Single P -30 ±20 -2.5 34 55 -------- -------- 930 -7.5 1.9
FKQ4953 　 TSOP6 Dual P -20 ±12 -1.2 -------- 100 140 -------- 677 -3 1.25
FKQ2903 　 TSOP6 Complementary N 20 ±12 1.2 -------- 55 75 -------- 310 3.5 1.14
　 P -20 ±12 -1.2 -------- 100 140 -------- 677 -2.5 1.14
FKQ2901 　 TSOP6 Complementary N 20 ±12 1.0 -------- 50 75 100 670 3.8 1.1
　 P -20 ±12 -1.0 -------- 70 95 115 686 -2.5 1.1
FKQ3909 　 TSOP6 Complementary N 30 ±12 1.2 60 65 85 -------- 662 3.8 1.1
　 P -30 ±12 -1.2 115 145 200 -------- 710 -2.3 1.1
FKR3002 　 TO251 Single N 30 ±20 2.5 18 30 -------- -------- 572 30 25
FKR3004 　 TO251 Single N 30 ±20 2.5 8.5 14 -------- -------- 1317 55 41.6
FKR3006 　 TO251 Single N 30 ±20 2.5 5.5 9 -------- -------- 2295 80 53
FKR3008 　 TO251 Single N 30 ±20 2.5 25 38 -------- -------- 416 24 20.8
FKR3016 　 TO251 Single N 30 ±20 2.5 4 6 -------- -------- 3075 93 62.5
FKR4016 　 TO251 Single N 40 ±20 2.5 6.5 9 -------- -------- 3354 75 52.1
FKR6006 　 TO251 Single N 60 ±20 2.5 20 24 -------- -------- 2423 35 45
FKR6008 　 TO251 Single N 60 ±20 2.5 90 100 -------- -------- 511 10 20.8
FKR6016 　 TO251 Single N 60 ±20 2.5 12 15 -------- -------- 3240 47 52
FKR6016A 　 TO251 Single N 60 ±20 5 12 -------- -------- -------- 2186 47 52
FKR6018A 　 TO251 Single N 60 ±20 4.5 8.2 -------- -------- -------- 1990 76 89.3
FKR6032 　 TO251 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 75 41
FKR6040 　 TO251 Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 112 104
FKR6056 　 TO251 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1270 58 52
FKR6056E V TO251 Single N 60 ±20 2.3 8.5 12.5 -------- -------- 1010 60 52
FKR8014 　 TO251 Single N 80 ±20 2.5 100 115 -------- -------- 1090 11.8 31.3
FKR8016 　 TO251 Single N 80 ±20 2.5 12 14.5 -------- -------- 3120 62 89
FKR0004 　 TO251 Single N 100 ±20 2.5 112 120 -------- -------- 1535 12 34.7
FKR0008 　 TO251 Single N 100 ±20 2.5 310 320 -------- -------- 508 5.4 20.8
FKR0014 　 TO251 Single N 100 ±20 2.5 152 158 -------- -------- 1077 9 31
FKR0016 　 TO251 Single N 100 ±20 2.5 47 50 -------- -------- 3848 22 52.1
FKR0018A 　 TO251 Single N 100 ±20 4.5 22 -------- -------- -------- 1890 45 90
FKR0020A 　 TO251 Single N 100 ±20 4.5 13 --------- -------- -------- 2947 56 83
FKR0026 　 TO251 Single N 100 ±20 2.5 18 24 -------- -------- 1930 49 90
FKR0040 　 TO251 Single N 100 ±20 2.4 14 17 -------- -------- 4708 70 89
FKR0048 　 TO251 Single N 100 ±20 2.3 8.5 11 -------- -------- 3320 73 108
FKR0094 　 TO251 Single N 100 ±20 2.4 11.5 15 -------- -------- 2550 58 73
FKR3031 　 TO251 Single P -30 ±20 -2.5 7.2 12 -------- -------- 3450 -70 90
FKR3101 　 TO251 Single P -30 ±20 -2.5 42 78 -------- -------- 585 -20 25
FKR3105 　 TO251 Single P -30 ±25 -2.5 15 25 -------- -------- 2215 -45 45
FKR3115 　 TO251 Single P -30 ±25 -2.5 10.5 18.5 -------- -------- 3448 -57 52.1
FKR6103 　 TO251 Single P -60 ±20 -2.5 70 105 -------- -------- 1447 -18 34.7
FKR6115 　 TO251 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -35 52.1
FKS3002 　 SOP8 Single N 30 ±20 2.5 18 26 -------- -------- 583 7 1.5
FKS3004 　 SOP8 Single N 30 ±20 2.5 9 14 -------- -------- 1317 10.3 1.5
FKS3006 　 SOP8 Single N 30 ±20 2.5 6 9 -------- -------- 2295 13 1.5
FKS3008 　 SOP8 Single N 30 ±20 2.5 25 38 -------- -------- 416 6.2 1.5
FKS3014 　 SOP8 Single N 30 ±20 2.5 12 18 -------- -------- 940 9 1.5
FKS3016 　 SOP8 Single N 30 ±20 2.5 4 6 -------- -------- 3075 15 1.5
FKS3018B 　 SOP8 Single N 30 ±20 2.5 3 3.8 -------- -------- 4345 24 3.1
FKS3056 　 SOP8 Single N 30 ±20 2.2 3.9 6.1 -------- -------- 1476 20 3.1
FKS3058 　 SOP8 Single N 30 ±20 2.2 8 11 -------- -------- 693 15 3.1
FKS4002 　 SOP8 Single N 40 ±20 2.5 26 35 -------- -------- 593 5.5 1.5
FKS4004 　 SOP8 Single N 40 ±20 2.5 12 17 -------- -------- 1314 10 1.5
FKS4006 　 SOP8 Single N 40 ±20 2.5 7.5 10 -------- -------- 2332 10.5 1.5
FKS4014 　 SOP8 Single N 40 ±20 2.5 17 22 -------- -------- 1013 7.2 1.5
FKS4016 　 SOP8 Single N 40 ±20 2.5 6.5 9 -------- -------- 2354 12.7 1.5
FKS4052 　 SOP8 Single N 40 ±20 2.5 8.5 15 -------- -------- 690 14 2.5
FKS4058 　 SOP8 Single N 40 ±20 2.2 9 14 -------- -------- 669 10.8 1.67
FKS4062 　 SOP8 Single N 40 ±20 2.4 15 23 -------- -------- 376 9.5 2.08
FKS4094 　 SOP8 Single N 40 ±20 2.2 3.2 5.3 -------- -------- 2648 24 22
FKS6004 　 SOP8 Single N 60 ±20 2.5 30 38 -------- -------- 1378 4.8 1.5
FKS6006 　 SOP8 Single N 60 ±20 2.5 20 24 -------- -------- 2423 6.3 1.5
FKS6008 　 SOP8 Single N 60 ±20 2.5 90 100 -------- -------- 511 3 1.5
FKS6014 　 SOP8 Single N 60 ±20 2.5 40 50 -------- -------- 1027 4.5 1.5
FKS6016 　 SOP8 Single N 60 ±20 2.5 12 15 -------- -------- 3240 8 1.5
FKS6032 　 SOP8 Single N 60 ±20 2.5 8.5 12 -------- -------- 3307 13 2.7
FKS6040 　 SOP8 Single N 60 ±20 2.5 5.2 7 -------- -------- 4706 18 3.1
FKS6048 　 SOP8 Single N 60 ±20 2.3 3.6 5.4 -------- -------- 3458 16 1.67
FKS6054 　 SOP8 Single N 60 ±20 2.3 12 18 -------- -------- 760 10.4 2.1
FKS8016 　 SOP8 Single N 80 ±20 2.5 12 14.5 -------- -------- 3120 11 2.8
FKS8048 　 SOP8 Single N 80 ±20 2.3 7 9 -------- -------- 2860 17.5 3.1
FKS0004 　 SOP8 Single N 100 ±20 2.5 112 120 -------- -------- 1535 2.5 1.5
FKS0014 　 SOP8 Single N 100 ±20 2.5 152 158 -------- -------- 1077 2 1.5
FKS0016 　 SOP8 Single N 100 ±20 2.5 47 50 -------- -------- 3848 3.6 1.5
FKS0026 　 SOP8 Single N 100 ±20 2.5 20 25 -------- -------- 1930 7.5 2.5
FKS0032 　 SOP8 Single N 100 ±20 2.5 24 28 -------- -------- 3307 8 2.7
FKS0040 　 SOP8 Single N 100 ±20 3 14 17 -------- -------- 4708 11 3.1
FKS0048 　 SOP8 Single N 100 ±20 2.3 8 10.5 -------- -------- 3320 13.5 3.1
FKS0056 　 SOP8 Single N 100 ±20 2.2 20 30 -------- -------- 849 9.3 3.1
FKS0094 　 SOP8 Single N 100 ±20 2.3 12 15.5 -------- -------- 2550 11.5 3.1
FKS3202 　 SOP8 Dual N 30 ±20 2.5 18 28 -------- -------- 572 7.3 1.5
FKS3204 　 SOP8 Dual N 30 ±20 2.5 10 16 -------- -------- 1317 11 2
FKS3206 　 SOP8 Dual N 30 ±20 2.5 6 10 -------- -------- 2295 13 1.5
FKS3208 　 SOP8 Dual N 30 ±20 2.5 25 38 -------- -------- 416 6.2 1.5
FKS3214 　 SOP8 Dual N 30 ±20 2.5 12 18 -------- -------- 940 9 1.5
FKS4204 　 SOP8 Dual N 40 ±20 2.5 15 20 -------- -------- 1314 7.5 1.5
FKS4214 　 SOP8 Dual N 40 ±20 2.5 20 26 -------- -------- 1013 8 1.9
FKS6204 　 SOP8 Dual N 60 ±20 2.5 32 38 -------- -------- 1378 4.8 1.5
FKS6208 　 SOP8 Dual N 60 ±20 2.5 90 100 -------- -------- 511 3 1.5
FKS6214 　 SOP8 Dual N 60 ±20 2.5 50 60 -------- -------- 1027 4 1.5
FKS8214 　 SOP8 Dual N 80 ±20 2.5 100 115 -------- -------- 1090 2.6 1.5
FKS0204 　 SOP8 Dual N 100 ±20 2.5 112 120 -------- -------- 1535 2.5 1.5
FKS0208 　 SOP8 Dual N 100 ±20 2.5 310 320 -------- -------- 508 1.5 1.5
FKS0214 　 SOP8 Dual N 100 ±20 2.5 152 158 -------- -------- 1077 2.2 1.5
FKS0228 　 SOP8 Dual N 100 ±20 2.9 68 94 -------- -------- 620 4 2
FKS2627 　 SOP8 Single P -20 ±8 -1.0 -------- 9 11.5 15 5783 -10.7 1.5
FKS3031 　 SOP8 Single P -30 ±20 -2.5 7 11 -------- -------- 3450 -16.8 3.1
FKS3101 　 SOP8 Single P -30 ±20 -2.5 42 78 -------- -------- 585 -5.5 1.5
FKS3103 　 SOP8 Single P -30 ±20 -2.5 20 32 -------- -------- 1345 -9.5 3.1
FKS3105 　 SOP8 Single P -30 ±20 -2.5 15 25 -------- -------- 2215 -11.5 1.5
FKS3107 　 SOP8 Single P -30 ±20 -2.5 62 110 -------- -------- 463 -5 1.5
FKS3113 　 SOP8 Single P -30 ±20 -2.5 30 55 -------- -------- 930 -6 1.5
FKS3115 　 SOP8 Single P -30 ±25 -2.5 8.7 13.5 -------- -------- 3448 -14 1.5
FKS4101 　 SOP8 Single P -40 ±20 -2.5 65 100 -------- -------- 620 -4 1.5
FKS4103 　 SOP8 Single P -40 ±20 -2.5 32 46 -------- -------- 1415 -5.6 1.5
FKS4105 　 SOP8 Single P -40 ±20 -2.2 22 30 -------- -------- 2370 -9.8 1.67
FKS4113 　 SOP8 Single P -40 ±20 -2.5 40 70 -------- -------- 1004 -7.5 3.1
FKS4115 　 SOP8 Single P -40 ±20 -2.5 13 20 -------- -------- 3500 -8.7 1.5
FKS6101 　 SOP8 Single P -60 ±20 -2.5 140 190 -------- -------- 715 -3 1.5
FKS6103 　 SOP8 Single P -60 ±20 -2.5 70 105 -------- -------- 1447 -3.7 1.5
FKS6105 　 SOP8 Single P -60 ±20 -2.5 35 55 -------- -------- 2217 -7.8 3.1
FKS6107 　 SOP8 Single P -60 ±20 -2.5 180 266 -------- -------- 531 -2.2 1.5
FKS6113 　 SOP8 Single P -60 ±20 -2.5 90 115 -------- -------- 1080 -4.1 3.1
FKS6115 　 SOP8 Single P -60 ±20 -2.5 25 33 -------- -------- 3635 -11 5.2
FKS0103 　 SOP8 Single P -100 ±20 -2.5 210 240 -------- -------- 1228 -1.8 1.5
FKS0107 　 SOP8 Single P -100 ±20 -2.5 650 700 -------- -------- 553 -1.5 1.5
FKS0115 　 SOP8 Single P -100 ±20 -2.5 95 110 -------- -------- 3029 -3 1.5
FKS01P15 　 SOP8 Single P -150 ±20 -4 780 -------- -------- -------- 706 -1.1 2
FKS3301 　 SOP8 Dual P -30 ±20 -2.5 45 82 -------- -------- 632 -4.9 1.5
FKS3303 　 SOP8 Dual P -30 ±20 -2.5 25 42 -------- -------- 1345 -6.5 1.5
FKS3305 　 SOP8 Dual P -30 ±25 -2.5 16 28 -------- -------- 2215 -9 2
FKS4313 　 SOP8 Dual P -40 ±20 -2.5 45 75 -------- -------- 1004 -6.5 3.1
FKS6303 　 SOP8 Dual P -60 ±20 -2.5 70 105 -------- -------- 1447 -3.7 1.5
FKS3437 　 SOP8 Single P -30 ±20 -2.5 10.5 16 -------- -------- 2967 -14 3.1
FKS3901 　 SOP8 Complementary N 30 ±20 2.5 27 40 -------- -------- 416 6 1.5
　 P -30 ±20 -2.5 32 56 -------- -------- 930 -5.7 1.5
FKS3903 　 SOP8 Complementary N 30 ±20 2.5 18 28 -------- -------- 572 10 2
　 P -30 ±20 -2.5 30 55 -------- -------- 930 -7.6 2
FKS3905 　 SOP8 Complementary N 30 ±20 2.5 12 18 -------- -------- 940 9 1.5
　 P -30 ±20 -2.5 15 25 -------- -------- 2215 -11.5 1.5
FKS3907 　 SOP8 Complementary N 30 ±20 2.5 27 40 -------- -------- 416 6.2 1.5
　 P -30 ±20 -2.5 62 110 -------- -------- 463 -4 1.5
FKS4402 　 SOP8 Asymmetric N 40 ±20 2.5 17 22 -------- -------- 1013 7.2 1.5
　 N 40 ±20 2.5 8.5 12 -------- -------- 2332 10.5 1.5
FKS4901 　 SOP8 Complementary N 40 ±20 2.5 26 35 -------- -------- 593 6.1 1.67
　 P -40 ±20 -2.5 32 46 -------- -------- 1415 -6 1.67
FKS4903 　 SOP8 Complementary N 40 ±20 2.5 28 42 -------- -------- 593 7.2 2.5
　 P -40 ±20 -2.5 40 65 -------- -------- 1004 -6.5 3.1
FKS4905 　 SOP8 Complementary N 40 ±20 2.5 28 42 -------- -------- 593 7.2 2.5
　 P -40 ±20 -2.5 65 100 -------- -------- 620 -4 1.5
FKS4907 　 SOP8 Complementary N 40 ±20 2.5 18 25 -------- -------- 1013 10 3.1
　 P -40 ±20 -2.5 40 70 -------- -------- 1004 -7.5 3.1
FKS6901 　 SOP8 Complementary N 60 ±20 2.5 32 38 -------- -------- 1378 4.8 1.5
　 P -60 ±20 -2.5 70 105 -------- -------- 1447 -3.7 1.5
FKS6903 　 SOP8 Complementary N 60 ±20 2.5 52 75 -------- -------- 1027 5 2
　 P -60 ±20 -2.5 100 105 -------- -------- 1137 -3.8 2
FKS0903 　 SOP8 Complementary N 100 ±20 2.5 100 125 -------- -------- 987 3 2.1
　 P -100 ±20 -2.5 220 255 -------- -------- 1228 -2.1 2.1
FKUA2544 　 SOT323 Single N 20 ±12 1.0 -------- 80 100 120 310 1.6 0.37
FKUB2546 V SOT523 Single N 20 ±8 1.0 -------- 450 760 850 47 0.7 0.4
FKUC2302 　 SOT23S Single N 20 ±12 1.2 -------- 60 80 -------- 310 3.6 1
FKUC2510 　 SOT23S Single N 20 ±12 1.0 -------- 26 35 50 670 6 1
FKUC3502 　 SOT23S Single N 30 ±12 1.2 27 32 40 -------- 860 5.8 1
FKUC3504 　 SOT23S Single N 30 ±12 1.2 -------- 40 47 -------- 662 3.9 1
FKUC6002 　 SOT23S Single N 60 ±20 2.5 85 100 -------- -------- 695 3 1.25
FKUC6008 　 SOT23S Single N 60 ±20 2.5 100 110 -------- -------- 511 2.3 1
FKUC2301 　 SOT23S Single P -20 ±12 -1.0 -------- 100 135 240 677 -3.3 1.4
FKUC2601 　 SOT23S Single P -20 ±12 -1.0 -------- 60 80 100 857 -3.4 1
FKUC2609 　 SOT23S Single P -20 ±12 -1.2 -------- 75 105 -------- 686 -3.1 1
FKUC2611 　 SOT23S Single P -20 ±12 -1.0 -------- 45 60 85 857 -4.9 1.31
FKUC3101 　 SOT23S Single P -30 ±20 -2.5 52 90 -------- -------- 583 -3.3 1
FKUC3107 　 SOT23S Single P -30 ±20 -2.5 70 120 -------- -------- 463 -3.2 1
FKUC3601 　 SOT23S Single P -30 ±12 -1.2 53 60 80 -------- 920 -4.3 1.4
FKY0076A 　 TOLL Single N 100 ±20 4 1.9 -------- -------- -------- 13362 316 333


Part Number Package MOSFET Type VDS(V) Cfg. ID(A) / TA=25 VTH(V) Max. Ron 4.5v (mΩ)Max. Ron 10v (mΩ)Max.
SOT223 N 30 Single 5.8 2.5 40 28
SOT223 N 60 Single 2.8 2.5 110 100
SOT223 N 60 Single 5 2.5 60 50
SOT223 N 100 Single 2.2 2.5 320 310
SOT223 N 100 Single 3 2.5 120 112
SOT223 N 100 Single 3.3 2.5 120 100
SOT223 N 100 Single 3 2.5 82 75
SOT223 N 100 Single 6 2.5 50 47
SOT223 N 200 Single 1.5 3 1100 1000
SOT223 P -30 Single -3.9 -2.5 120 70
SOT223 P -30 Single -4.5 -2.5 90 52
SOT223 P -30 Single -5.8 -2.5 45 32
SOT223 P -60 Single -4.3 -2.5 190 130
SOT223 P -60 Single -2.3 -2.5 266 180
SOT223 P -100 Single -1.5 -2.5 700 650
SOT23 N 20 Single 3.6 1.2 55 --------
SOT23 N 20 Single 6 1.0 26 --------
SOT23 N 30 Single 3.9 1.2 40 --------
SOT23 N 30 Single 5.8 1.2 32 27
SOT23 N 30 Single 4.6 2.5 50 33
SOT23 N 30 Single 5 2.5 40 28
SOT23 N 40 Single 4.5 2.5 50 37
SOT23 N 40 Single 5 2.5 45 32
SOT23 N 60 Single 2.3 2.5 110 100
SOT23 N 100 Single 1.2 2.5 320 310
SOT23 N 100 Single 2 2.5 175 160
SOT23 P -20 Single -3 -1.0 100 --------
SOT23 P -20 Single -3.1 -1.2 75 --------
SOT23 P -20 Single -4 -1.2 60 --------
SOT23 P -20 Single -4.9 -1.0 45 --------
SOT23 P -20 Single -4.7 -1.0 32 --------
SOT23 P -30 Single -3.2 -1.2 80 60
SOT23 P -30 Single -4.3 -1.2 65 55
SOT23 P -30 Single -3.2 -2.5 120 70
SOT23 P -30 Single -3.3 -2.5 90 52
SOT23 P -30 Single -4.2 -2.5 62 40
SOT23 P -30 Single -4.8 -2.5 45 32
SOT23 P -40 Single -3.2 -2.5 100 70
SOT23 P -60 Single -1.7 -2.5 266 180
SOT23 P -100 Single -0.9 -2.5 700 650
SOT23S N 20 Single 3.6 1.2 60 --------
SOT23S N 20 Single 6 1.0 26 --------
SOT23S N 30 Single 3.9 1.2 40 --------
SOT23S N 30 Single 5.8 1.2 32 27
SOT23S N 60 Single 2.3 2.5 110 100
SOT23S N 60 Single 3 2.5 100 85
SOT23S P -20 Single -3.3 -1.0 100 --------
SOT23S P -20 Single -3.1 -1.2 75 --------
SOT23S P -20 Single -3.4 -1.0 60 --------
SOT23S P -20 Single -4.9 -1.0 45 --------
SOT23S P -30 Single -4.3 -1.2 60 53
SOT23S P -30 Single -3.3 -2.5 90 52
SOT23S P -30 Single -3.2 -2.5 120 70
SOT323 N 20 Single 1.6 1.0 80 --------
SOT523 N 20 Single 0.7 1.0 450 --------
SOT89 N 30 Single 5.8 2.5 40 28
SOT89 N 40 Single 6 2.5 55 40
SOT89 N 60 Single 2.8 2.5 110 100
SOT89 N 100 Single 2.2 2.5 320 310
SOT89 P -30 Single -3.9 -2.5 120 70
SOT89 P -30 Single -4 -2.5 90 52
SOT89 P -30 Single -5 -2.5 62 40
SOT89 P -30 Single -5.8 -2.5 45 32
SOT89 P -40 Single -5.8 -2.5 100 70
SOP8 N 30 Single 6.2 2.5 38 25
SOP8 N 30 Single 7 2.5 26 18
SOP8 N 30 Single 9 2.5 18 12
SOP8 N 30 Single 10.3 2.5 14 9
SOP8 N 30 Single 13 2.5 9 6
SOP8 N 30 Single 15 2.5 6 4
SOP8 N 30 Single 24 2.5 3.8 3
SOP8 N 30 Single 15 2.2 11 8
SOP8 N 30 Single 20 2.2 6.1 3.9
SOP8 N 40 Single 7.5 2.5 38 28
SOP8 N 40 Single 8.4 2.5 22 17
SOP8 N 40 Single 10 2.5 17 12
SOP8 N 40 Single 14 2.5 15 8.5
SOP8 N 40 Single 10.5 2.5 10 7.5
SOP8 N 40 Single 9.5 2.4 23 15
SOP8 N 60 Single 3 2.5 100 90
SOP8 N 60 Single 4.5 2.5 50 40
SOP8 N 60 Single 4.8 2.5 38 30
SOP8 N 60 Single 6.3 2.5 24 20
SOP8 N 60 Single 8 2.5 15 12
SOP8 N 60 Single 13 2.5 12 8.5
SOP8 N 60 Single 18 2.5 8.5 6.5
SOP8 N 80 Single 11 2.5 14.5 12
SOP8 N 100 Single 2 2.5 158 152
SOP8 N 100 Single 2.5 2.5 120 112
SOP8 N 100 Single 3.6 2.5 50 47
SOP8 N 100 Single 8 2.5 28 24
SOP8 N 100 Single 8.5 2.5 25 20
SOP8 N 100 Single 11 2.4 17 14
SOP8 N 100 Single 11.5 2.3 15.5 12
SOP8 N 100 Single 13.5 2.3 10.5 8
SOP8 P -20 Single -10.7 -1.0 9 --------
SOP8 P -30 Single -5 -2.5 110 62
SOP8 P -30 Single -5.5 -2.5 78 42
SOP8 P -30 Single -7.5 -2.5 55 30
SOP8 P -30 Single -9.5 -2.5 32 20
SOP8 P -30 Single -11.5 -2.5 25 15
SOP8 P -30 Single -14 -2.5 13.5 8.7
SOP8 P -30 Single -16.8 -2.5 11 7
SOP8 P -40 Single -4 -2.5 100 65
SOP8 P -40 Single -7.5 -2.5 70 40
SOP8 P -40 Single -8 -2.5 46 32
SOP8 P -40 Single -8.7 -2.5 20 13
SOP8 P -60 Single -2.2 -2.5 266 180
SOP8 P -60 Single -3 -2.5 190 140
SOP8 P -60 Single -4.1 -2.5 115 90
SOP8 P -60 Single -3.7 -2.5 105 70
SOP8 P -60 Single -11 -2.5 33 25
SOP8 N 30 Dual 6.2 2.5 38 25
SOP8 N 30 Dual 7.3 2.5 28 18
SOP8 N 30 Dual 11 2.5 16 10
SOP8 N 30 Dual 9 2.5 18 12
SOP8 N 30 Dual 13 2.5 10 6
SOP8 N 40 Dual 8 2.5 26 20
SOP8 N 40 Dual 7.5 2.5 20 15
SOP8 N 60 Dual 3 2.5 100 90
SOP8 N 60 Dual 4.5 2.5 50 40
SOP8 N 60 Dual 4.8 2.5 38 32
SOP8 N 80 Dual 2.6 2.5 115 100
SOP8 N 100 Dual 1.5 2.5 320 310
SOP8 N 100 Dual 2.2 2.5 158 152
SOP8 N 100 Dual 2.5 2.5 120 112
SOP8 N 100 Dual 4 2.9 94 68
SOP8 P -30 Dual -4.9 -2.5 82 45
SOP8 P -30 Dual -6.5 -2.5 42 25
SOP8 P -30 Dual -9 -2.5 28 16
SOP8 P -40 Dual -6.5 -2.5 75 45
SOP8 P -60 Dual -3.7 -2.5 105 70
SOP8 N 40 Asymmetric 7.2 2.5 22 17
SOP8 N 40 Asymmetric 10.5 2.5 12 8.5
SOP8 P -30 Asymmetric -14 -2.5 16 10.5
SOP8 N 30 Complementary 6.2 2.5 40 27
SOP8 P -30 Complementary -4 -2.5 110 62
SOP8 N 30 Complementary 6 2.5 40 27
SOP8 P -30 Complementary -5.7 -2.5 56 32
SOP8 N 30 Complementary 6 2.5 28 18
SOP8 P -30 Complementary -5.7 -2.5 55 30
SOP8 N 30 Complementary 9 2.5 18 12
SOP8 P -30 Complementary -6.5 -2.5 42 25
SOP8 N 40 Complementary 7.2 2.5 42 28
SOP8 P -40 Complementary -4 -2.5 100 65
SOP8 N 40 Complementary 7.2 2.5 42 28
SOP8 P -40 Complementary -6.5 -2.5 65 40
SOP8 N 40 Complementary 6.1 2.5 35 26
SOP8 P -40 Complementary -6 -2.5 46 32
SOP8 N 40 Complementary 10 2.5 25 18
SOP8 P -40 Complementary -7.5 -2.5 70 40
SOP8 N 60 Complementary 5 2.5 75 52
SOP8 P -60 Complementary -3.8 -2.5 105 100
SOP8 N 60 Complementary 4.8 2.5 38 32
SOP8 P -60 Complementary -3.7 -2.5 105 70
TSOP6 N 20 Single 4.5 1.2 37 --------
TSOP6 N 30 Single 5 2.5 40 28
TSOP6 N 30 Single 8 2.5 18 12.5
TSOP6 P -20 Single -6.9 -1.0 30 --------
TSOP6 P -30 Single -5 -2.5 83 52
TSOP6 N 20 Dual 6 1.2 24.5 --------
TSOP6 N 20 Dual 5.5 1.2 23.5 --------
TSOP6 N 20 Dual 6 1.2 20 --------
TSOP6 N 20 Dual 7 1.2 17 --------
TSOP6 N 60 Dual 2.5 2.5 110 100
TSOP6 P -20 Dual -3 -1.2 100 --------
TSOP6 N 20 Complementary 3.5 1.2 55 --------
TSOP6 P -20 Complementary -2.5 -1.2 100 --------
TSOP6 N 20 Complementary 3.8 1.0 50 --------
TSOP6 P -20 Complementary -2.5 -1.0 70 --------
TSSOP8 N 20 Dual 4.5 1.0 30 --------
TSSOP8 N 20 Dual 6 1.2 25 --------
TSSOP8 N 20 Dual 7 1.2 18.5 --------
TSSOP8 N 20 Dual 7 1.2 14.5 --------
TO220 N 30 Single 37 2.5 30 18
TO220 N 30 Single 53 2.5 18 12
TO220 N 30 Single 90 2.5 9 6
TO220 N 30 Single 110 2.5 6 4
TO220 N 30 Single 205 2.5 3.8 2.7
TO220 N 40 Single 90 2.5 8.5 6.5
TO220 N 40 Single 170 2.2 3.6 2.6
TO220 N 40 Single 165 4.5 -------- 3.3
TO220 N 60 Single 14 2.5 100 90
TO220 N 60 Single 26 2.5 50 40
TO220 N 60 Single 30 2.5 38 30
TO220 N 60 Single 45 2.5 24 20
TO220 N 60 Single 60 2.5 15 12
TO220 N 60 Single 85 2.5 8.5 6.5
TO220 N 60 Single 60 5 -------- 12
TO220 N 60 Single 75 4.5 -------- 8.5
TO220 N 60 Single 98 4.5 -------- 8.2
TO220 N 60 Single 170 4.5 -------- 4.8
TO220 N 80 Single 100 2.5 14.5 12
TO220 N 80 Single 108 4 -------- 6.5
TO220 N 100 Single 11.8 2.5 158 152
TO220 N 100 Single 18 2.5 120 112
TO220 N 100 Single 27 2.5 50 47
TO220 N 100 Single 75 2.3 15 11.5
TO220 N 100 Single 80 2.3 12 9
TO220 N 100 Single 58 4.5 -------- 22
TO220 N 100 Single 70 4.5 --------- 14
TO220 N 100 Single 104 4.5 -------- 12
TO220 N 200 Single 18 2.5 180 170
TO220 P -30 Single -60 -2.5 22 14
TO220 P -30 Single -74 -2.5 18.5 10.5
TO220 P -60 Single -17 -2.5 115 90
TO220 P -60 Single -23 -2.5 105 70
TO220 P -60 Single -40 -2.5 55 35
TO220 P -60 Single -45 -2.5 35 27
TO220 P -100 Single -23 -2.5 110 95
TO220 P -100 Single -35 -2.5 55 50
TO220F N 60 Single 20 2.5 38 30
TO220F N 60 Single 30 2.5 24 20
TO220F N 60 Single 38 2.5 15 12
TO220F N 60 Single 67 2.5 7 5.2
TO220F N 60 Single 80 2.3 6.5 4.5
TO220F N 100 Single 17.5 2.5 50 47
TO220F N 100 Single 48 2.3 10.5 8
TO220F N 100 Single 27 4.5 -------- 22
TO220F N 100 Single 60 4.5 -------- 12
TO220F P -40 Single -41 -2.5 20 13
TO220F P -60 Single -15 -2.5 105 70
TO251 N 30 Single 24 2.5 38 25
TO251 N 30 Single 30 2.5 30 18
TO251 N 30 Single 55 2.5 14 8.5
TO251 N 30 Single 80 2.5 9 5.5
TO251 N 30 Single 93 2.5 6 4
TO251 N 60 Single 10 2.5 100 90
TO251 N 60 Single 35 2.5 24 20
TO251 N 60 Single 47 2.5 15 12
TO251 N 60 Single 112 2.5 7 5.2
TO251 N 60 Single 47 5 -------- 12
TO251 N 80 Single 11.8 2.5 115 100
TO251 N 80 Single 62 2.5 14.5 12
TO251 N 100 Single 5.4 2.5 320 310
TO251 N 100 Single 9 2.5 158 152
TO251 N 100 Single 12 2.5 120 112
TO251 N 100 Single 22 2.5 50 47
TO251 N 100 Single 49 2.5 24 18
TO251 N 100 Single 70 2.4 17 14
TO251 N 100 Single 73 2.3 11 8.5
TO251 N 100 Single 45 4.5 -------- 22
TO251 N 100 Single 56 4.5 --------- 13
TO251 P -30 Single -20 -2.5 78 42
TO251 P -30 Single -45 -2.5 25 15
TO251 P -30 Single -57 -2.5 18.5 10.5
TO251 P -30 Single -70 -2.5 12 7.2
TO251 P -60 Single -35 -2.5 33 25
TO252 N 30 Single 24 2.5 38 25
TO252 N 30 Single 30 2.5 30 18
TO252 N 30 Single 43 2.5 18 12
TO252 N 30 Single 55 2.5 14 8.5
TO252 N 30 Single 80 2.5 9 5.5
TO252 N 30 Single 96 2.5 6 4
TO252 N 30 Single 70 2.5 3.2 2.4
TO252 N 40 Single 23 2.5 38 28
TO252 N 40 Single 40 2.5 24 16.5
TO252 N 40 Single 42 2.5 16.5 11.5
TO252 N 40 Single 60 2.5 10 7.5
TO252 N 40 Single 75 2.5 9 6.5
TO252 N 40 Single 70 4 -------- 3.3
TO252 N 60 Single 10 2.5 100 90
TO252 N 60 Single 17 2.5 90 70
TO252 N 60 Single 20 2.5 50 40
TO252 N 60 Single 23 2.5 38 30
TO252 N 60 Single 35 2.5 24 20
TO252 N 60 Single 47 2.5 15 12
TO252 N 60 Single 75 2.5 12 8.5
TO252 N 60 Single 112 2.5 7 5.2
TO252 N 60 Single 47 5 -------- 12
TO252 N 60 Single 75 4.5 -------- 8.5
TO252 N 60 Single 76 4.5 -------- 8.2
TO252 N 75 Single 62 2.5 14.5 12
TO252 N 80 Single 11.8 2.5 115 100
TO252 N 80 Single 48 2.3 8.5 6.5
TO252 N 100 Single 5.4 2.5 320 310
TO252 N 100 Single 9 2.5 158 152
TO252 N 100 Single 12 2.5 120 112
TO252 N 100 Single 14.6 2.9 110 100
TO252 N 100 Single 14 2.9 85 66
TO252 N 100 Single 22 2.5 50 47
TO252 N 100 Single 30 2.5 32 26
TO252 N 100 Single 40 2.5 28 22
TO252 N 100 Single 73 2.3 11 8.5
TO252 N 100 Single 45 4.5 -------- 22
TO252 N 100 Single 56 4.5 -------- 13.5
TO252 N 150 Single 20 2.5 100 88
TO252 N 150 Single 30 2.5 50 46
TO252 N 150 Single 23 4 -------- 56
TO252 N 200 Single 18 2.5 180 170
TO252 P -30 Single -15.4 -2.5 110 62
TO252 P -30 Single -20 -2.5 78 42
TO252 P -30 Single -27 -2.5 55 30
TO252 P -30 Single -35 -2.5 32 20
TO252 P -30 Single -45 -2.5 25 15
TO252 P -30 Single -57 -2.5 15 9.8
TO252 P -30 Single -70 -2.5 12 7.2
TO252 P -40 Single -22 -2.5 100 65
TO252 P -40 Single -24 -2.5 70 40
TO252 P -40 Single -32 -2.5 46 32
TO252 P -40 Single -42 -2.5 20 13
TO252 P -60 Single -12 -2.5 190 140
TO252 P -60 Single -8 -2.5 266 180
TO252 P -60 Single -13 -2.5 115 90
TO252 P -60 Single -18 -2.5 105 70
TO252 P -60 Single -35 -2.5 33 25
TO252 P -100 Single -4.1 -2.5 700 650
TO252 P -100 Single -18 -2.5 110 95
TO252 P -100 Single -30 -2.5 55 50
TO252-4L N 30 Complementary 6 2.5 40 27
TO252-4L P -30 Complementary -5.7 -2.5 56 32
TO252-4L N 30 Complementary 6 2.5 28 18
TO252-4L P -30 Complementary -5.7 -2.5 55 30
TO252-4L N 40 Complementary 23 2.5 42 28
TO252-4L P -40 Complementary -42 -2.5 70 40
TO252-4L N 60 Complementary 20 2.5 50 40
TO252-4L P -60 Complementary -12 -2.5 125 100
TO252-4L N 60 Complementary 23 2.5 38 32
TO252-4L P -60 Complementary -18 -2.5 105 70
TO263 N 30 Single 65 2.5 14 8.5
TO263 N 30 Single 90 2.5 9 6
TO263 N 30 Single 205 2.5 3.2 2.4
TO263 N 60 Single 45 2.5 24 20
TO263 N 60 Single 50 2.5 12 8.5
TO263 N 60 Single 116 2.5 7 5.2
TO263 N 60 Single 98 4.5 -------- 8.2
TO263 N 60 Single 160 4.5 -------- 4.8
TO263 N 75 Single 80 2.5 14.5 12
TO263 N 100 Single 36 2.5 50 40
TO263 N 100 Single 40 2.5 28 22
TO263 N 100 Single 58 4.5 -------- 22
TO263 N 100 Single 104 4.5 -------- 12
TO263 N 100 Single 120 4 -------- 4.5
TO263 P -60 Single -45 -2.5 33 25
DFN2*2 N 20 Complementary 5 1.0 40 --------
DFN2*2 P -20 Complementary -4.5 -1.0 100 --------
DFN2*3 N 20 Dual 11 1.5 7.2 --------
DFN2*3 N 20 Dual 9.5 1.5 9 --------
DFN2*3 N 20 Dual 8 1.2 16 --------
DFN2*3 N 20 Dual 8 1.2 13 --------
DFN3*3 N 12 Dual 56 1.0 4.3 --------
DFN3*3 N 20 Dual 56 1.0 5.8 --------
DFN3*3 N 30 Dual 30 2.5 18 12
DFN3.3*3.3 N 20 Single 50 1.0 2 --------
DFN3.3*3.3 N 60 Single 50 2.5 12 8.5
DFN3.3*3.3 P -30 Single -50 -2.5 12 7.2
PRPAK3*3 N 30 Single 50 1.0 5.5 4.9
PRPAK3*3 N 30 Single 28 2.5 30 18
PRPAK3*3 N 30 Single 37 2.5 16.5 12
PRPAK3*3 N 30 Single 46 2.5 13 8.5
PRPAK3*3 N 30 Single 40 2.5 9 5.5
PRPAK3*3 N 30 Single 80 2.5 6 4
PRPAK3*3 N 30 Single 30 2.5 9 6.3
PRPAK3*3 N 30 Single 36 2.4 19 12.5
PRPAK3*3 N 30 Single 12 2.2 15.8 9.8
PRPAK3*3 N 30 Single 28 2.2 11 8
PRPAK3*3 N 30 Single 50 2.2 9 5.2
PRPAK3*3 N 30 Single 35 2.2 6.1 3.9
PRPAK3*3 N 40 Single 43 2.5 15 8.5
PRPAK3*3 N 40 Single 40 2.5 9 6.5
PRPAK3*3 N 40 Single 33 2.4 23 15
PRPAK3*3 N 60 Single 33 2.5 24 20
PRPAK3*3 N 60 Single 44 2.5 15 12
PRPAK3*3 N 60 Single 30 2.3 12.5 8.5
PRPAK3*3 P -20 Single -48 -1.0 9 --------
PRPAK3*3 P -30 Single -32 -2.5 32 20
PRPAK3*3 P -30 Single -42 -2.5 22 14
PRPAK3*3 P -30 Single -50 -2.5 13.5 8.7
PRPAK3*3 P -60 Single -26 -2.5 33 25
PRPAK3*3 NEP N 20 Dual 7 1.2 17 --------
PRPAK3*3 NEP N 20 Dual 12 1.5 10.5 --------
PRPAK3*3 N 30 Dual 28 2.5 30 18
PRPAK3*3 N 30 Dual 25 2.5 19.5 14
PRPAK3*3 N 100 Dual 4.6 3 360 330
PRPAK3*3 N 30 Complementary 24 2.5 30 20
PRPAK3*3 P -30 Complementary -27 -2.5 30 18
PRPAK3*3 NEP N 30 Complementary 6 2.5 55 32
PRPAK3*3 NEP P -30 Complementary -5 -2.5 110 70
PRPAK3*3 NEP N 30 Complementary 7 2.5 40 28
PRPAK3*3 NEP P -30 Complementary -7 -2.5 56 32
PRPAK3*3 NEP N 30 Complementary 10 2.5 28 18
PRPAK3*3 NEP P -30 Complementary -8 -2.5 55 30
PRPAK5*6 N 30 Single 50 2.5 18 12
PRPAK5*6 N 30 Single 58 2.5 14 8.5
PRPAK5*6 N 30 Single 81 2.5 9 5.5
PRPAK5*6 N 30 Single 108 2.5 6 4
PRPAK5*6 N 30 Single 85 2.5 3.2 2.4
PRPAK5*6 N 30 Single 52 2.5 9 6.3
PRPAK5*6 N 30 Single 75 2.5 5.8 3.8
PRPAK5*6 N 30 Single 40 2.4 19 12.5
PRPAK5*6 N 30 Single 28 2.2 15.8 9.8
PRPAK5*6 N 30 Single 30 2.2 11 8
PRPAK5*6 N 30 Single 50 2.2 9 5.2
PRPAK5*6 N 30 Single 73 2.2 6.1 3.9
PRPAK5*6 N 30 Single 85 2.2 3.6 2.2
PRPAK5*6 N 30 Single 100 2.2 2.5 1.6
PRPAK5*6 N 40 Single 46 2.5 16.5 11.5
PRPAK5*6 N 40 Single 60 2.5 10 7.5
PRPAK5*6 N 40 Single 33 2.5 22 17
PRPAK5*6 N 40 Single 75 2.5 9 6.5
PRPAK5*6 N 40 Single 50 3 15 8.5
PRPAK5*6 N 40 Single 114 2.2 5.3 3.2
PRPAK5*6 N 40 Single 100 2.2 2.6 1.8
PRPAK5*6 N 60 Single 40 2.5 20 18
PRPAK5*6 N 60 Single 52 2.5 15 12
PRPAK5*6 N 60 Single 75 2.5 12 8.5
PRPAK5*6 N 60 Single 116 2.5 7 5.2
PRPAK5*6 N 60 Single 85 2.3 5.4 3.6
PRPAK5*6 N 60 Single 85 4.5 -------- 4.8
PRPAK5*6 N 60 Single 85 4 -------- 3.6
PRPAK5*6 N 75 Single 62 2.5 14.5 12
PRPAK5*6 N 80 Single 60 2.3 13 8.7
PRPAK5*6 N 80 Single 48 2.3 8.5 6.5
PRPAK5*6 N 80 Single 122 4 -------- 6.5
PRPAK5*6 N 100 Single 58 2.5 23.5 18.5
PRPAK5*6 N 100 Single 64 2.4 17 14
PRPAK5*6 N 100 Single 60 2.4 15 11.5
PRPAK5*6 N 100 Single 78 2.3 10.5 8
PRPAK5*6 N 100 Single 55.6 4.5 -------- 22
PRPAK5*6 N 100 Single 60 4.5 -------- 13
PRPAK5*6 N 100 Single 104 4.5 -------- 10
PRPAK5*6 N 100 Single 60 4 -------- 11.5
PRPAK5*6 N 100 Single 78 4 -------- 8
PRPAK5*6 P -30 Single -35 -2.5 32 20
PRPAK5*6 P -30 Single -31 -2.5 55 30
PRPAK5*6 P -30 Single -70 -2.5 12 7.2
PRPAK5*6 P -30 Single -45 -2.5 25 15
PRPAK5*6 P -30 Single -59 -2.5 15 9.8
PRPAK5*6 P -60 Single -35 -2.5 33 25
PRPAK5*6 P -100 Single -8 -2.5 55 50
PRPAK5*6 N 30 Dual 35 2.5 14 8.5
PRPAK5*6 N 40 Asymmetric 39 2.5 22 17
PRPAK5*6 N 40 Asymmetric 54 2.5 12 8.5
PRPAK5*6 N 40 Complementary 15 2.5 10 8
PRPAK5*6 P -40 Complementary -15 -2.5 20 13
PRPAK5*6 N 100 Single 100 4 -------- 4.5
PRPAK3*3 N 30 Complementary 19 2.5 50 34
PRPAK3*3 P -30 Complementary -18.7 2.5 60 36
PRPAK5*6 N 40 single 100 2.2 2.6 1.8
TO263 N 40 single 170 2.2 3.6 2.6
TO220 N 40 single 170 2.2 3.6 2.6
PRPAK3*3 N 60 Dual 29 2.5 21 15
PRPAK3*3 N 60 Single 33 2.5 18 12
SOP8 P -150 Single -1.1 -4 980 780
PRPAK5*6 N 30 Single 230 2.2 1.7 1.1
PRPAK3*3 NEP N 100 Complementary 2 2.5 320 310
PRPAK3*3 NEP P -100 Complementary -1.5 -2.5 700 650
TO252 N 30 Single 72 2.2 9 5.5
PRPAK3*3 N 60 Single 5 2.5 70 50
PRPAK3*3 P -60 Single -3.8 -2.5 120 100
