| FLYiNG 零件編號 | ICUT9435HGSO8RUTC |
| FLYiNG 庫存現貨 | 35,000 |
| 製造商 | UTC |
| 製造商零件編號 | UT9435HG-S08-R |
| 說明 | UT9435HG-S08-R SOP-8 UTC |
| 無鉛狀態 / RoHS 指令狀態 | RoHS / Halogen Free |
| 封裝／外殼 | SOP-8 |
| 標準包裝數量 | 2500/REEL |
| VDSS | VGSS | ID | RDS(ON) | VGS(th) | CISS | COSS | CRSS | ||||||
| Configuration | Part No. | (V) | (V) | (A) | VGS=10V (mΩ) (Max) |
VGS=4.5V (mΩ) (Max) |
VGS=2.5V (mΩ) (Max) |
(V) (Min) |
(V) (Max) |
(pF) (Typ) |
(pF) (Typ) |
(pF) (Typ) |
Package |
| P-CH | UT9435 | -30 | ±20 | -4.2 | 50 | 90 | - | -1.0 | -3.0 | 520 | 180 | 130 | SOT-89 |
| P-CH | UT9435 | -30 | ±20 | -4.2 | 50 | 90 | - | -1.0 | -3.0 | 520 | 180 | 130 | SOP-8 |
| P-CH | UT9435 | -30 | ±20 | -4.2 | 50 | 90 | - | -1.0 | -3.0 | 520 | 180 | 130 | TO-252 |
| P-CH | UT9435-H | -30 | ±20 | -4.2 | 50 | 90 | - | -1.0 | -3.0 | 1040 | 420 | 150 | DFN-6(2X2) |
| P-CH | UT9435H | -30 | ±20 | -5.3 | 50 | 90 | - | -1.0 | -3.0 | 1040 | 420 | 150 | SOT-23 |
| P-CH | UT9435H | -30 | ±20 | -5.3 | 50 | 90 | - | -1.0 | -3.0 | 1040 | 420 | 150 | SOT-26 |
| P-CH | UT9435H | -30 | ±20 | -5.3 | 50 | 90 | - | -1.0 | -3.0 | 1040 | 420 | 150 | SOT-223 |
| P-CH | UT9435H | -30 | ±20 | -5.3 | 50 | 90 | - | -1.0 | -3.0 | 1040 | 420 | 150 | SOP-8 |
| P-CH | UT9435HZ | -30 | ±20 | -5.3 | 55 | 135 | - | -1.0 | -3.0 | 600 | 95 | 85 | SOT-23 |
| P-CH | UT9435HZ | -30 | ±20 | -5.3 | 55 | 135 | - | -1.0 | -3.0 | 600 | 95 | 85 | SOT-26 |
| P-CH | UT9435HZ | -30 | ±20 | -5.3 | 55 | 135 | - | -1.0 | -3.0 | 600 | 95 | 85 | SOT-223 |
| P-CH | UT9435HZ | -30 | ±20 | -5.3 | 55 | 135 | - | -1.0 | -3.0 | 600 | 95 | 85 | SOP-8 |
