| FLYiNG 零件編號 | ICUT7500G30T92CKUTC |
| FLYiNG 庫存現貨 | 5 |
| 製造商 | UTC |
| 製造商零件編號 | UT7500G-3.0V-T92-C-K |
| 說明 | CMOS IC UT7500G-30-T92-C-K TO-92 |
| 無鉛狀態 / RoHS 指令狀態 | RoHS / Halogen free |
| 電源管理 LDO | CMOS IC |
| 製造商 | UTC |
| 系列 | UT7500 |
| 原廠料號 | UT7500G-30-T92-C-K |
| 電源電壓VCC | -0.3 ~ +26V |
| 輸入電壓VIN | 24V |
| 輸出電壓Vout | 3V |
| 電壓降 VD | 100mV |
| 功耗 | 內部受限 |
| 工作溫度 | -40~85°C |
| 封裝／外殼 | TO-92 |
| 安裝類型 | DIP引腳 |
| 無鉛狀態 RoHS | RoHS / Halogen free |
| 標準包裝數量 | 1000/散裝 |
文件:UT7500 UTC.png)
無衝突金屬聲明書
UT7500 CMOS IC
HIGH DRIVER REGULATOR
DESCRIPTION
The UTC UT7500 series is a low voltage regulator implemented by CMOS technology which is composed of a three-terminal high current. The input voltage for it is allowed as high as 24V and the output voltage are fixed at 1.8V, 2.5V, 3.0V、3.3V、3.6V、4.0V and 5.0V. Besides, it delivers 100mA output current. Other outstanding features of UTC UT7500 include low voltage drop and low quiescent current.
When being used with external components, UTC UT7500 can obtain variable voltages and currents.
UTC UT7500 series is very suitable for applications, such as battery-powered equipment, communication equipment and audio/video equipment.
FEATURES
UT7500 CMOS集成電路
高壓驅動調節器
描述
UTC UT7500系列是採用CMOS技術實現的低壓穩壓器，由三端大電流組成。 它的輸入電壓允許高達24V，輸出電壓固定為1.8V、2.5V、3.0V、3.3V、3.6V、4.0V和5.0V。 此外，它還提供 100mA 的輸出電流。 UTC UT7500 的其他突出特點包括低電壓降和低靜態電流。
與外部元件配合使用時，UTC UT7500 可以獲得可變電壓和電流。
UTC UT7500系列非常適用於電池供電設備、通信設備和音頻/視頻設備等應用。
特徵
無衝突金屬聲明書
UT7500 CMOS IC
HIGH DRIVER REGULATOR
DESCRIPTION
The UTC UT7500 series is a low voltage regulator implemented by CMOS technology which is composed of a three-terminal high current. The input voltage for it is allowed as high as 24V and the output voltage are fixed at 1.8V, 2.5V, 3.0V、3.3V、3.6V、4.0V and 5.0V. Besides, it delivers 100mA output current. Other outstanding features of UTC UT7500 include low voltage drop and low quiescent current.
When being used with external components, UTC UT7500 can obtain variable voltages and currents.
UTC UT7500 series is very suitable for applications, such as battery-powered equipment, communication equipment and audio/video equipment.
FEATURES
- Very Low Power Consumption
- Very Low Voltage Drop
- Very Low Temperature Coefficient
- Up to 24V Input Voltage
- 100mA @ PD ≤ 250mW Output Current
- Tolerance ±3%
UT7500 CMOS集成電路
高壓驅動調節器
描述
UTC UT7500系列是採用CMOS技術實現的低壓穩壓器，由三端大電流組成。 它的輸入電壓允許高達24V，輸出電壓固定為1.8V、2.5V、3.0V、3.3V、3.6V、4.0V和5.0V。 此外，它還提供 100mA 的輸出電流。 UTC UT7500 的其他突出特點包括低電壓降和低靜態電流。
與外部元件配合使用時，UTC UT7500 可以獲得可變電壓和電流。
UTC UT7500系列非常適用於電池供電設備、通信設備和音頻/視頻設備等應用。
特徵
- 非常低的功耗
- 非常低的電壓降
- 極低溫度係數
- 高達 24V 的輸入電壓
- 100mA @ PD ≤ 250mW 輸出電流
- 公差 ±3%
