DATE - 2019/09/23
COMCHIP 7月份 Product Announcement
親愛的朋友

  7月 COMCHIP  二極體新產品發表會。

相關發表資訊可參考下列Specification



Comchip Product Announcement 2019July .pdf下載

Bridge Diode
COMCHIP P/N Package Specification
CSPB30K-HF/CSPB30M-HF SPB VRRM=800/1000V, IFSM=90A, IF=3A, VF=1V, IR=1uA,
CSPB40K-HF/CSPB40M-HF SPB VRRM=800/1000V, IFSM=135A, IF=4A, VF=1V, IR=1uA
CSPB60K-HF SPB VRRM=800V, IFSM=170A, IF=6A, VF=1V, IR=1uA

Switch Diode
COMCHIP P/N Package Specification
MMBD914-HF SOT-23 IF=200mA, VRRM=75V, VF=1.25V, Trr=4ns, IR=30uA,

General Purpose Rectifiers (AECQ)
COMCHIP P/N Package Specification
AS1D-HF – AS1M-HF SMA IF=1A, VRRM=1000V, IFSM=30A, VF=1.1V, IR=5uA, SMA

Schottky Diode
COMCHIP P/N Package Specification
CDBQT140-HF 0402/DFN1006 IF=1A, VRRM=40V, IFSM=7A, VF=0.61V, IR=40uA,
CDBVRL140-HF 0603/DFN1608 IF=1A, VRRM=40V, IFSM=5A, VF=0.55V, IR=50uA,
CDBVRL240-HF 0603/DFN1608 IF=2A, VRRM=40V, IFSM=15A, VF=0.58V, IR=20uA,

MOSFET
COMCHIP P/N Package Specification
CMSBN4612-HF CSPB1313-4 Dual N, PD=1.4W, VDS=22V, ID=2A, VGS=12V, RDSON=36mΩ,
CMSBN4615-HF CSPB1515-4 Dual N, PD=1.5W, VDS=2(V, ID=7A, VGS=12V, RDSON=26mΩ ,
CMSBN4616-HF CSPB1515-4 Dual N, PD=1.5W, VDS=15V, ID=8A, VGS=12V, RDSON=18mΩ ,
CMSBN6601-HF CSPB2718-6 Dual N, PD=2W, VDS=20V, ID=13A, VGS=12V, RDSON=11.5mΩ

Digital Transistor
COMCHIP P/N Package Specification
DTC113ZUA-HF SOT-323 IC=100mA, Vin=-5 to +10, Io=100mA, R1/R2=1K/10K,
DTC114WUA-HF SOT-323 IC=100mA, Vin=-10 to +30, Io=100mA, R1/R2=10K/4.7K
DTC114YUA-HF SOT-323 IC=100mA, Vin=-6 to +40, Io=70mA, R1/R2=10K/47K
DTC123JUA-HF SOT-323 IC=100mA, Vin=-5 to +12, Io=100mA, R1/R2=2.2K/47K
DTC123YUA-HF SOT-323 IC=100mA, Vin=-5 to +12, Io=100mA, R1/R2=2.2K/10K
DTC143XUA-HF SOT-323 IC=100mA, Vin=-7 to +20, Io=100mA, R1/R2=4.7K/10K
DTC143ZUA-HF SOT-323 IC=100mA, Vin=-5 to +30, Io=100mA, R1/R2=4.7K/47K

ESD Diode
COMCHIP P/N Package Specification
CPDV3V0-HF~CPDV24V0-HF SOD-323 Ppp=350W, VRWM=3~24V, Cj=0.8pF, IPP=8A
CPDV3V3A-HF SOD-323 (Bi) Ppp=100W, VRWM=3.3V, VBR=4.2V, Cj=0.4pF
CPDH3V3-HF SOD-523 (Bi) Ppp=350W VRWM=3.3V, VBR=4V, Cj=45pF,
CPDV5V0A-HF SOD-323 (Bi) Ppp=400W, VRWM=5V, VBR=5.8V, Cj=40pF
CPDH5V0A-HF SOD-523 (Bi) Ppp=400W, VRWM=5V, VBR=5.8V, Cj=40pF
CPDH2V5UB-HF SOD-523 (Ui) Ppp=104W, VRWM=2.5V, VBR=4V, Cj=45pF
CPDH3V3UB-HF SOD-523 (Ui) Ppp=105W, VRWM=5V, VBR=5V, Cj=105pF
